1300
Molex Wiring Connectors
VT No.  OEM
Female Connectors
32-9673  72512-07BK  3 Position   Black
32-9697  72514-07GY  3 Position   Grey
32-9675  72177-04BK  4 Position  Black
32-9677  72414-07BK  6 Position  Black
32-9678  72479-07BK  8 Position  Black
32-9691  72469-07GY  8 Position  Grey
32-9679  72487-07BK  12 Position  Black
32-9692  72489-07GY  12 Position  Grey
32-9680  72166-07BK  16 Position  Black
32-9693  72491-07GY  16 Position  Grey
32-9681  72500-07BK  20 Position  Black
32-9699  72473-07
Blade Cavity Plugs Pack of 10
32-9700  72169-07
16-20 Gauge Stamped Pins, 100 pk
32-9701  72168-07
16-20 Gauge Stamped Sockets, 100 pk
Molex MX150 Wiring Connectors
Socket Housing
AMP  OEM#
VT No.
U/M
2 73152-96BK
32-6508 2
3 73153-96BK
32-6509 2
4 73153-96BK
32-6510 2
6 73156-96BK
32-6511 2
8 73158-96BK
32-6512 1
AMP Multi-Lock Wire Connectors
AMP Wire Connectors
VT No.  OEM
Wiring Pin Housing
32-6501  73102-96BK
2 Position
32-6502  73103-96BK
3 Position
32-6503  73104-96BK
4 Position
32-6504  73106-96BK
6 Position
32-6505  73108-96BK
8 Position
VT No.  OEM
Wiring Socket Housing
32-6508  73152-96BK
2 Position
32-6509  73153-96BK
3 Position

73154-96BK
4 position
32-6511  73156-96BK
6 Position
32-6512  73158-96BK
8 Position
32-6500  73190-96
16-20 Gauge (Pin Terminal Pack of 10)
32-0936  73191-96
16-20 Gauge (Socket Terminal Pack of 10)
32-6509
32-6501
32-6502
32-6503
32-6504
32-6505
32-6508
32-6512
32-6500
32-0936
32-6511
Pin Housing
AMP
OEM#
VT No.    U/M
2 73102-96BK
32-6501   2
3 73103-96BK
32-6502   2
4 73104-96BK
32-6503   2
6 73106-96BK
32-6504   2
8 73108-96BK
32-6505   1
32-6500
32-0936
32-6501
32-6502
32-6503
32-6504
32-6505
32-6509
32-6511
32-6512
AMP
OEM#
VT No.    U/M
Pin 73190-96
32-6500   10
Socket 73191-96
32-0936   10
32-6508
Radio and BCM Connector Kit will
work in both locations on all 2014-up
models with CAN/Bus. Includes 3 dif-
ferent gauge size terminals. Replaces
OEM# 69200193.
VT No. 32-9712
On Board Power Ports plug into on-board diagnostic port.
100% plug nā€™ play. Acts like a cigarette lighter port in your
automobile. Works great for powering and charging accesso-
ries while riding. Made in U. S. A.
VT No.
Fits
32-6579*  1994-13 FLT, FLTR, FLHR, FLHT, FLHX and H-D
FL Trikes
32-5062
2011-13 FLST, 12-13 FXD, and 2014-16 models
Can. bus
*Note: Designed to fit into leading edge of removal side panel
cover.
Switched Circuit Adapter Harness allows two accessories
to be connected to the switched accessory circuit. Allow two
accessories to be turned on or off simultaneous Works great for
testing using the OBPP and keeping your optional accessory
plugged in at the same time.
VT No.
Fits
32-5058
1994-13 All FLT models
32-5059
2011-up FXST, FLST, 2012-17 FXD, 2014-up XL,

2014-up FLT
Electrical Connection Update Kit. This harness plugs into
accessory connector and provide 12 volt power leads. Use when
installing audio, tachometer and oil pressure gauges, fuel lever
gauges and heated grips.
VT No.
Fits
32-5057
2014-up XL, 2012-17 FXD and 2011-17 FXST, FLST
32-5060
2014-16 All FLT models
Spotlamp Adapter Wiring Harness allows mounting of late-
style 4 1/2ā€ auxiliary spot lamps equipped with spade connectors
on pre-05 models. Sold each. Requires two harnesses.
VT No.
Fits
32-5063
Auxilliary Lamp Wiring Harness

repl. OEM# 68355-05
LED Headlamp Adapter Harness use when installing
Daymaker type LED headlamps.
VT No.
Fits
32-5064
For 2014-18 Touring models and HD FL Trike
(except FLHR/FLTRX)

Replacing 69200897
32-5065
For 2004-13 FLTR, replacing OEM# 69200533
VT No.  OEM
  Male Connectors
32-9682  72511-07BK  3 Position  Black
32-9694  72513-07GY  3 Position  Grey
32-9685  72175-07BK  4 Position  Black
32-9690  72188-07BK  6 Position  Black
32-9686  72478-07BK  8 Position  Black
32-9687  72447-07GY  8 Position   Grey
32-9695  72488-07BK  12 Position  Black
32-9688  72490-07GY  12 Position  Grey
32-9689  72177-07BK  16 Position  Black
32-9698  72492-07GY  16 Position  Grey
32-5060
32-5058
32-5064
32-5062
32-5063
