Tool presses the inner cam
bearings smoothly into the
right case with the bearings
installed to the proper depth.
use on all 1958-98 Big Twin
VT No.16-0660
if the cam is too tight or loose in the 9058 Torrington
Bearing on 1958-98 Big Twins. Set of 2.
VT No. 16-0684
will size the hole to .030 so the oversize breather can
be used for 1936-98 models.
VT No. 16-0695
precise fit for selection. Sold in
pairs.
VT No.
16-1750 .108
Rods install needle bearings without damage.
Bushing tool positions pinion bushing in cam cover on
all 1970-98 Big Twin to correct depth.
VT No.
includes easy to read
degree wheel dial indica-
tor, T.D.C. locator, light-
weight checking springs
and packed in a plastic
case. Also checks cam
or crank end play, shaft
and gear run out. Use on
all Big Twins 1936-98.
VT No. 16-0970
instructions for the mechanic to install Crane’s adjust-
able pushrods without removing the gas tank or rock-
er covers. In all FL-FX with adjustable pushrods, the
tool makes it easy for cam changes. No removal of
pushrods, pushrod covers, tappets or tappet guides.
Tappets never have to fall out of the guides while
doing cam changes. Use on all Big Twins 1936-98.
VT No. 16-0030
Bushing Plate Pilot and
Reamer. Reams in board
camshaft and camshaft crank-
case bushing, replaces 38871.
VT No. 16-1823
VT No. OEM
Puller easily removes
74 and 80 cam cover on
1970-98 models.
VT No. 16-0839
Alignment Tool aligns to within .0003” of the center
line. Any binding of this tool indicates misalignment of
cam cover and or bushing.
VT No. 16-0671 (A) (Jims)
1936-69 Cam Cover Bushing Remover Tool removes
bushing in one operation. Fits Overhead Valve (OHV).
VT No.
16-1043 B Sifton
1970-98 Big Twin Covers while
removing and installing bush-
ings. Holds cover flat, to avoid
scratches.
VT No. 16-0858
is used to remove the pinion
bushing from the cam cover on
1954-98 Big Twins.
VT No. 16-1822
can be used to remove or install
seal and will also remove cover
from case. Fits Big Twin, 1970-98.
VT No. 16-0675
lation and drilling of a dowel pin to factory location
supplied with #31 drill by Jims.
Cam Bushing Drill Jigs
VT No.
Pinion Bushing Drill Jigs
VT No.
remove and replace the spring loaded
cam chain tensioners. Fits 1999-2006
FLT, 2000-2006 FLST, 2000-2006
FXST,1999-05 FXD.
is required 2017-up FLT and 2018-up FXST, FLST
M-8 models. This tool holds tighter tolerances which
allows for a more precise installation depth.
well as "Jims" fine threaded installation driver.
VT No. 16-1185
