Hitachi Type Starters are replicas for 1974-76, Parts inter-
change with original, 5” overall body length.
VT No.
OEM
Item
32-7760  31570-73
Complete, Black
32-1307
Complete, Black
32-7761  31570-73
Complete, Chrome
32-0306 31580-73  Armature
32-7769  31575-81
Brush Set, 1981-90 XL only
32-0307  31582-73
Brush Set
32-0308  31579-73
Field Coils
32-0059  31576-73
Thru Bolts
12-0347  31583-73
Bearing, Drive End
Starter Brush Spring for Hitachi Starter
Motors 1973-up.
VT No.  OEM
Years
13-0223 31593-73  1973-80
13-9157  31557-81
1981-up, Compression
13-9220  31600-90
1990-up, Starter Clutch Assembly
Hitachi Starter Hardware Kit includes
brushes, holder, springs, thru bolts and insu-
lator commutator end bushing for 1973-80.
VT No. 32-0553
Starter Motor Clamp Fits 1973-80. Replaces
31473-67 in stainless.
VT No. 31-0099
Prestolite Type Starter Motor replaces Prestolite starter used
on 1967-73 XL, 1977-80 XL models. Chromed unit is complete-
ly chromed. 6” overall body length.
VT No.  OEM
Item
32-7524  31458-66A Complete, Chrome
32-7525  31458-66A Complete, Black
32-1308
Complete, Black
32-0303 31542-66  Armature
32-0680  31540-66  Field Coil Set
32-0592  31535-66  Thru Bolts
12-0325 31539-66  Bearing
1.4 KW
Warranty
All Electrical Components sold as individual pieces or in kits are covered under
our warranty “Replacement Only” Provision. All electrical related item part num-
bers begin with a 32 prefix. No credit will be issued for these items as they are
exchange only.
32-7524
32-7525
32-7761
32-7760
13-0223
Starter Relays
VT No.  #  OEM
Fits

Brand
32-0640  A  71463-73A  1975-79 XL
Accel
32-0641  B  71463-73A  As Above
V-Twin, Replica
32-0642  C  31506-79
1980-90 All
32-0738  D        —
As Above with Weather Proof Skirt
32-9076  E  31504-91A  1991-03 All XL
32-0643    71455-67
1967-E68, L71-74 XL
32-0185 F 71455-67
1967-E68
32-0768  G  31601-04
2004-11 XL
32-1160    31586-07
2012-up XL
Starter Relay Connectors
VT No.    OEM
Fits
32-8036   72046-79C  1979-up All Twins
32-8041   4-lug
1973-78 All Twins


   when using


1979-90 type starter relay
32-8042   5-lug
As Above
Note: 32-8036 includes crimp style connector ends and
32-8041 and 32-8042 includes pigtail harness.
32-9076
32-0737
C
D
E
G
32-0185
F
Start Boost Relay will reduce 12v voltage drop in
single fire ignition applications during cranking will
allow full battery voltage to the module and coil.
VT No. 32-3000
Replica Starter Motor
32-8036
32-8041
32-8042
32-0643
32-0642
32-0738
32-0640
B
A
Starter Relay
32-0740
High Torque Starter Motor features 1.4 kw design that gen-
erates more power and shaft speed than original type .8 kw
starter.
VT No.
Finish
Type
32-5122 Black
Hitachi
32-1634 Black
V-Twin
32-5123 Chrome
Hitachi
32-5120 Black
Prestolite
32-5123
32-5122
32-0303
32-1308
32-0641
