955
XL
Alternator Rotor by Volt Tech features
vibration proof magnet construction, as
magnets are held in place by a stainless
steel non-magnetic insert for durability.
Unit includes sprocket. OE type has stock
type magnets.
VT No.
Teeth Year
32-9099
35 1991-2003
32-0024
38
2004-up 1200cc
32-0030
34
2004-up 883cc
Alternator Rotor Clutch Shell Assembly
feature vibration proof magnet construc-
tion, as magnets are held in place by stain-
less steel non-magnetic insert for durability.
Replaces 36791-84. Fits 1984-90. Bearing
and ring gear included.
VT No. 18-8324
Stators replace stock units for models listed in
unmolded type. 32-0965 features heavy duty copper
windings.
VT No.  Brand
Type
1985-89 XL, Replaces 29967-84A, 19 Amp
32-7566
 Volt Tech
Unmolded
32-9043 Accel

Unmolded
32-9044 Accel

Molded
1990-06 XL, Replaces 29967-89A, 22 Amp
32-9230
Volt Tech
Unmolded
32-0965 Volt Tech
Unmolded
32-9046 Accel

Unmolded
2007-13 XL, Replaces 29900067, 32 Amp
32-0958
 Volt Tech
Unmolded
32-9099
Back Side of 32-9099
Unmolded
Volt-Tech Charging System for XL models.
Complete kits include rotor, stator, regulator
and all hardware necessary for complete instal-
lation.
Sportster Single Phase Kits
VT No.  Year
Teeth
Amp
32-0471  1991-93
35
19
32-0472  1994-03
35
20
32-0023   2004-06  1200
38
20
32-0025   2004-06  883
34
20
32-1464   2007-08  1200
38
27
32-1465   2007-08  883
38
27
32-1466   2009-13  1200
38
27
32-1467   2009-13  883
34
27
Sportster Three Phase Kits
32-1468
 1991-03

38
32-1469 2004-06

38
Charging System fits
1984-90 XL models with
alternator in clutch drum.
Kit includes alternator
rotor clutch shell assem-
bly with bearing and ring
gear installed, which
features vibration proof
magnet construction,
as magnets are held in
place by stainless steel
non-magnetic insert, sta-
tor and regulator.
VT No.
Regulator
 Finish
32-0473
Chrome
32-1432 Black
32-0472
Charging System
Charging System Kit for XL’s developed by V-Twin in 1995
32-0473
Warranty
All Electrical Components sold as individual pieces or in kits are covered
under our warranty “Replacement Only” Provision. All electrical related item
part numbers begin with a 32 prefix. No credit will be issued for these items as
they are exchange only.
32-0965
32-0471
32-0025
32-0023
