952

Ignition Sensor Plate Assembly.
VT No. OEM

Fits

32-9020 32400-80A 1980-94 XL
32-0519 32400-94 1995-97 XL

32-9020

Crane H1-4N Multi Function

Performance Ignition Kit

includes ignition, single fire coil,

and 8.5mm double silicone spark plug wires.The HI-4N ignition

has a one piece machined aluminum housing which reduces

the vibration and improves dissipation and reliability. Ignition is

equipped with a single and dual fire function which is built into

a single module. Allows easy mode, advance rate, and rev limit

adjustments. Initial timing marks allow adjustment and reinstal-

lation. Sensor covers are integrated into the housing to provide

protection during installation. This is improved kickstart algorithm

designed to start easily, and with

a flexible wiring harness it makes

installation easier.

VT No. Item

32-1731 HI-4N Ignition

32-1732 HI-4N Kit

32-1732

Twin Tec Internal Ignition for 1970-99
Big Twin models and 1971-1997 XL. Two
advance curve families with adjustable
advance slope accommodate stock to highly
modified engines. Digitally set RPM Limit (100
RPM Steps). Selectable single or dual fire
mode. Coil outputs protected against short cir-
cuits. Optional PC link cable and software for
programming custom advance curve
VT No. Item
32-1005 Ignition
32-3053 As Above ARB E.O. No. D-641-1
32-2013 3.0 Ohm Single Fire Coil

Daytona Twin Tec
Internal Ignition Kit
for 1971-97 Sportster
models. Kit includes
ignition, coil and
spark plug wire set.
VT No. 32-3015

Daytona Twin Tec Internal Ignition Kit for 1998-03 Sportster
models (except 1200S). Kit includes matching Deutsch plug
and harness for single fire conversion, coil and spark plug wire
set.
VT No. Item
32-3016 Ignition Kit
32-3054

Above ARB E.O. No. D-641-1 & D-641-2

Daytona Twin Tec External
Ignition Kits include module, coil
and spark plug wire set.
VT No.   Fits
32-3017  1990-93 Sportster
32-3018  1994-99 Sportster

Sensor Cup Kit includes special screw to fit all
“Sensor” type ignition kits. Fits 1995-99.
VT No. 32-9124

Daytona Twin Tec External Single Fire Ignition Conversion
Kit includes 50 state street legal selectable ignition module,
sensor plate, rotor cup and adapter harness that allows use of
tachometer and single fire coil. Allows use of external ignition
on all 1970-1999 carbureted only Big Twins and 1971-2003 XL
models. Helps prevent heat related ignition failures by replacing
heat sensitive internal nose-cone style ignitions. Also available
as complete kit with correct 3.0 ohm single fire coil and plug
wire set.
VT No. Item
32-3047 Conversion Kit
32-3048 Complete Conversion Kit with Coil and Wires

32-3047

32-3048

Important Note:

Some items on this page may be emission-related parts subject to California or other emission control laws. Please

see note on for important information regarding emission control regulatory compliance and warranty information.

Replacement Ignition Modules bolt-on replacements.
Harness 32-9014 required as noted.
VT No. OEM

Fits

42-0399

Cover

32-2218 32466-95A 1995-97 XLH 883

42-0399

Compu-Fire Plug In Performance Ignition
Module features programmable advance curve,
RPM limit, Single Fire or Dual Fire operation, Accu-
Ray Timing light which simplifies installation and two

selectable levels of VOES control. Fits 1996-97 8 pin Deutsch
style.

Note: Each module has two pigtails and plug connector.

White lead goes to tach, red lead goes to the second coil for
single fire operation.

VT No. 32-2503

Twin Tec External Ignition for 2004-06 Carbureted XL
Models. Wide timing advance adjustment range accommodates
stock to highly modified engines. Features digitally set RPM Limit
(100 RPM Steps). Selectable multi-spark mode for quick starting
and smooth cruise. Coil outputs protected against short circuits.
Billet aluminum housing with black anodized finish. Easy plug-in
installation supports all sensors including theft/security module.
VT No. 32-1014

32-1014
