945

Chrome Coil Mount Bracket Kit
VT No.

Year

31-0131  1971-94
31-0321  1995-up
31-0758  2004-up

31-0131

31-0321

31-0758

Motor Mount for

XLH

Chrome Top Front Motor Mount replaces 16214-86, 1986-
2003 Evolution XL 1200 models.
VT No.

Item

31-0410 Mount
9967-4

Bolt Kit

9967-4

31-0410

Chrome Allen Bolt Set fits 2004-
up motor mounts.
VT No. 2228-16

Motor Mounts for 2004-up.
31-0715 Mount
31-1273  Tie Rod, Chrome
31-0862  Center Mount
31-0881  Tie Link Mount Bracket
31-0882  Rear Iso
31-0887  Front Iso
31-1280  Front Mount

Chrome Top Center Motor Mount for
1986-2003.
VT No. Year

OEM

31-0591 1986-94 16278-86A
31-0629 1995-03 16278-95B
42-0027 1986-94 Top Center Mount Cover

31-2137

Chrome Motor Mounts for Late 1984-2003
Evolution XL.
VT No.  Item
31-2137  Front Mount Set
9772-22  Allen As Above

31-0715

31-0862

31-0882

31-0887

1986-03 Bolt Sets
8871-13 Acorn Center
9773-8 Acorn, Cylinder Head

31-0881

2004-up Motor Mounts

1982-03

Chrome 1986-2003 XL Billet
Top Motor Mount accepts
coil bracket, horn. Solid motor
mount kit fits 2004-up XL.
VT No. Item
31-0713 Top Mount
42-0962 Coil Cover

Chrome Teardrop Coil Cover
fits top motor mounts with 2
holes such as 31-0664. Includes
key switch hole.

VT No. 42-0926

31-1273

31-0629

Front Isolator Mount Kit.
VT No.  Item
31-0848  2004-16
31-0849   2004-13
31-0850 2014-16

31-0848

31-0849

31-0850

31-1280

Coil Cover available in polished stainless or chrome.
VT No. Fits

Finish

42-0839 1983-03 Chrome
42-0039 1985-03

Stainless

42-0418 1971-78 Chrome

42-0418

42-0839

42-0039

Coil Mount Studs replace 64611-55, 64612-55
models, pairs. Fits 1955-67 XLH.
VT No. 37-9156

Black Top Mounts
VT No. Year
31-0011 1986-03
31-1357 2004-up

31-0011

31-1357

31-0591

42-0962

31-0713

Solid Motor Mount Kit for swingarm
and hardtail frames, features a natural
alloy finish. This 6 piece set includes
replacement motor mounts and 2 cov-
ers with hardware for the outside of the
rear mounts. These mounts eliminate
the shake while the motor is running.

VT No. 31-2004
