Single Disc Front Caliper
Assembly
features stock type
construction in black or chrome
with piston installed. Caliper
units include zinc plated brack-
ets and hardware. Fits 11¹⁄₂”
rotor on stock 35mm forks. Fits
1974-77.

VT No.
Finish
23-1730
Black
23-1737
Chrome
Chrome Caliper Kit Drilled includes
zinc or polished stainless steel brake
rotor. Fits 1974-77.
VT No.  Rotor  Type
23-0564
Steel   Chrome
23-0565 Steel Polished
23-1206 Steel  Black Caliper
1974-77 Front
Caliper Service Fix
Kit
includes seal
kit, spring, pins and
bleeder screw.
VT No. 23-0148
1974-77 Single Disc Caliper
1974-77 Single Disc Caliper Kit includes GMA Billet Caliper,
11.5” drilled zinc plated steel rotor and mount bolts.
VT No.   Item
23-0626
Kit
23-4513  Caliper Bracket Only GMA
23-0626
23-1737
23-0564
1974-77 Single Caliper Pieces.
VT  No.  #
OEM
Item
23-1723 K
44275-74   Piston
12-0943 L
44274-74   Piston, Friction Ring
23-0514 A&B  44281-74   Pad Set
23-0606 E&F  44277-74   Caliper Seal Kit

 44278-74
23-0148
Kit
Service Kit includes C,D,E,F,G,N
23-1747 C&D  44280-74   Caliper Pin Set, two piece


44283-74   Set


43302-77   Spring, Service Fix
23-1995 H
44272-74   Anchor Arm

44276-74   Plate, Floating Lining
23-0065


 Anchor Arm Only
37-8996 M
Kit
 Mount Bolt Kit Chrome
23-1730 J
Complete   Black Caliper Assembly with A-F+H,I
23-0711 N
41749-58   Bleeder Screw
8759-5  O
41191-74   Chrome Rotor Screw Set
1974-77 “Clover Leaf” 11
1
/
2
” Rotors.
VT No.  Finish

Brand
23-0303 Zinc
  Dura
23-0302  Zinc, Drilled  Dura
23-0317  Stainless
Dura
23-9042  SS Polished  Russell
23-0636  SS Polished  Dura
23-0303
1984-99 Chrome Billet Front Caliper Kit includes billet
chrome front caliper and bracket with pads and polished 18
spoke stainless steel brake rotor with bolts. Kit includes hard-
ware to fit 39 & 41mm forks FXST, FXD and FLST models.
VT No.   Item
23-0238  18 Spoke Kit
23-0240  Razor Kit
23-0279  Caliper & Bracket Only
23-0884  Caliper Rebuild fits V-Twin Billet 4 Piston Calipers
23-0238
Front Caliper Kit
23-0240
23-0279
23-0884
Front Caliper Assemblies are fully assembled with disc pads
and all internals for 1973 only XL front. Calipers accept 1/8”
NPT line.
Black Chrome
23-2219
  23-2237
23-2219
23-2237
11.5” Chrome Front Caliper and Rotor Kit includes a com-
plete chrome replica 4-piston caliper assembly with pads, pol-
ished stainless steel drilled rotor and chrome mount bolts.
VT No.
Year
23-0649
1984-99
23-0562
2000-03
23-0989 2004-up
23-0562
23-0649
23-0989
23-0302
23-0636
