Caliper Assemblies.
VT No. OEM
Year
Finish
23-0587 40925-00 2000-03
Chrome
23-0633 40968-04 2004 Chrome
23-0236 40968-05 2005-07
Chrome
23-0855 40968-08 2008-10
Chrome
23-1316 40968-11 2011-up
Black
23-1331 40968-11 2011-up
Chrome
23-9221 44198-87 L1987-99 Caliper
Chrome
23-9052 44052-82A 1982-E87 Caliper, Complete Chrome
37-0508 44201-82 Bolt Kit for Above
GMA Components.
23-4520 PA2
GMA Caliper Piston, pair, fits 23-4519, 23-9208, 23-9209
23-4510 RB1
Caliper O-Ring Seal Kit fits ,23-4519, 23-9208, 23-9209
23-4514 B-Pad
SBS Brake Pad Set fits Calipers: 23-4519, 23-9208, 23-9209
23-9936 R79FXL GMA Floating Brake Disc 1979-99 Rear
Chrome Rear Caliper Kit fits XL models and includes com-
plete chrome replica 4-piston caliper assembly with pads and
polished stainless steel drilled brake disc with chrome mount
bolts.
VT No.
Year
23-1150 2005-07
23-1097 2004
23-1092 2000-03
22-0369 1987-99
22-0366 1982-86
23-1097
22-0366
23-1150
23-1092
11.5” Chrome Caliper Kit
fits XL’s Rigid frames with
3/4” rear axle. Kit includes
polished 11.5” disc, bolts,
chrome 4-piston caliper com-
plete with integral bracket
and weld on frame tab for left
side.
VT No. 22-0370
Rear Caliper Kits include GMA Caliper with bracket and either
a polished or standard 11¹⁄₂” stainless steel rotor with mount
bolts. Use with ⁵₈” master cylinder.
Polished Standard Fits
22-0361 22-0354 1979-81
22-0362 22-0355 1982-Early87
22-0363 22-0356 Late1987-99
Rear Caliper
23-0369
22-0363
22-0356
Chrome Bracket for Calipers are sold
separately. Replaces 40929-87. Fits
L1987-99.
VT No. 23-9047
23-9047
23-9238
23-0137
23-0147
Rear GMA Billet Aluminum Brake Calipers are machined from billet
aluminum and clear anodized. Feature dual pistons which are internally
connected, brake pads and brackets, when provided. Include spacers
and hardware necessary for installation. Hoses and brake disc not
included. Use ⁵⁄₈” bore master cylinder.
VT No.
GMA
Model
23-9209
205
Late1987-99 XL with banjo bolts
23-9209
23-9209
Caliper
Installed
Vibration Shims fit rear pads.
VT No.
OEM
Year
23-9238 41665-82 1982-86
23-0137 43959-86 1987-99
23-0147 44337-00 2000-03
23-9268 42521-04 2004-13
23-9268
23-9221
23-0633
23-9052
23-0236
23-0855
23-0587
2004-up XL Standard models.
VT No.
Item
23-0680 Rear Pedal
21-0578 Chrome Shifter Lever
27-0817 Footpeg Support Left Side
23-0780 Footpeg Support Right Side
23-0680
21-0578
