872
1981-up Sprocket Cover and Hardware
Sprocket Cover Hardware. Fits XLS-XLH.
VT No. OEM
Years
Item
23-3024 34866-86A 1986-90
Mount Stud
23-3015 42441-80 1980-90
Pivot Stud
23-3079 42441-90 1991-2003 Pivot Shaft
23-1728 34909-83 1983-90
Master Cylinder
Support Bracket
23-3080 34933-96 1991-2003 Master Cylinder Support
Bracket
*Note: Fits belt and chain drive.
Sprocket Cover Screw Sets.
Acorn Allen Years
—
8786-5 1981-85
8866-8 9750-6 1986-2003
—
9750-6T 1986-2003
—
2226-4 2004-up
Acorn
Allen
23-3024
23-3079
23-1728
23-3080
42-0840
42-0843
Sprocket Cover Trim fits over existing cover for XL’s as noted.
Includes hardware.
Chrome Black
Fits
42-0840
1986-90
42-0843
1981-85
42-0845 42-0383 1991-2003
42-0930 42-0384 2004-up
42-0845
42-0930
Kick Starter Gear Kit
XLCH Internal Kick Starter Gear Kit has parts pictured,
matched ratchet gear set with sleeve, crank gear, spring, rivets,
locks, shaft and the hard to find hardware for XLCH repair or
XLH conversion. Only needed parts are a cover, kick starter
spring and arm assembly. 1980-up Sportsters are not drilled to
accept a kicker shaft.
VT No.
Fits
17-1144 1954-70
17-1145 1971-72
17-1146* 1973-79
*Note: Must be used with early style one piece kicker arm
VT No. 17-0308.
17-1146
XLCH Ratchet Gear Kit includes gear, plate, rivets, machined
spacer and spring for appropriate year. Spacer supplied as
noted.
VT No.
Year
Spacer
17-1103 1954-70
17-1100
17-1104 1971-72
17-1100
17-1105 1973-79
17-1102
42-0383
42-0384
23-3015
Outlaw Front Pulley Cover Guard and Pulley Cover. Outlaw
Front Pulley Cover replaces stock pulley cover for a high per-
formance look. Outlaw Pulley Cover adds the finishing touch by
filling in the center of pulley for a clean detailed look. Available
in either black or chrome finish. Fits 2004-up XL.
Chrome Black
43-0388 43-0389 Pulley Cover Kit
27-0832 27-0833 Pulley Cover Guard Kit
27-0832
27-0833
43-0389
43-0388
17-1105
