787
CLASSIC
Handlebar for Springer
Chrome Black  Type # Style
49-0322  49-0321
 Speedster  A-Inline


49-0510 Speedster  Brazed
49-0742  49-0741 Speedster  A-Inline
49-0762  49-0761 Speedster  Offset
49-0323  49-0324 Buckhorn  C-Inline
49-0484        Buckhorn C-Offset
49-0334       Speedster A-Offset
49-0327       Buckhorn C-Offset
49-0346       Standard B-Offset
36-0498
Internals
For Above
9217-4
Pinch Bolts Chrome
9218-4
Pinch Bolts Cadmium
9508-4
Pinch Bolts Parkerized
9508-4T
Pinch Bolts Parkerized
Spring Fork Handlebars fit inline stem
models 1936-57 45, 74 and 80 models,
offset 1946-48 Big Twin. Available in
black or chrome finish. Order pinch
bolts and head cone lock plate as listed.
See web for measurements.
49-0331
49-0323
B
Handlebar End Nuts.
VT No.  Years
Type
7625-2  1931-35 Parkerized
7626-2T  1931-35  Black Oxide
7626-2  1936-48 Parkerized
49-0957 1936-48  Parkerized
16-1262 1936-42  Tap
Upper Head Cone Lock Plate acts as
lock and top tree cover, polished stainless
steel has pin installed.
VT No.  Center Finish
49-0941
 Inline  Stainless Steel Replica
49-0805 Inline  Stainless Steel
49-0981 Offset  Polished Stainless Steel
49-0941
Do you have the OEM number? Check our data base from over 15,000 part numbers referenced by Factory OEM numbers.
www.vtwinmfg.com
16-1262
Throttle Brackets have parkerized finish and mounting hard-
ware as original.
Overhead Valve (OHV)
VT No.  OEM
Year
9005-4 3371-36
1936-48
31-0537 56605-49
1949-53
31-0973 Parkerized
1949-53
31-0787
1948
2041-7 45218-52
1971-72
49-1024
49-1029
49-1104
C
49-0321
49-3461  Inline Speedster
49-3463  Inline Speedster
Springer Handlebars feature Speedster design as original with
full brazed construction as the triple tree and throttle & spark
collars.
VT No.
Assembly  Type
Finish
Type
49-0510 49-1388  Speedster Black
NL
49-0005
Speedster Black
49-0015  49-0615
1936 EL  Black
NL
49-0018  49-0032
1936 EL  Chrome
NL
49-0013
1945-48  Raw
OS
49-0018
49-0015
49-0510
7626-2T
49-0022
Spring Fork Triple Tree. Raw for handlebars.
VT No.  Type


Finish
49-1024 Offset
Raw
49-1029 Inline
Raw
49-1104 Inline
Zinc
49-0022  Black, without ears
Black
49-0510
49-0510 Detail
49-0762
Throttle and Spark Cable Brackets have parkerized finish and
mounting hardware as original.
Side Valve (SV)
9006-4  B  3371-37
1937-48   Big Twin
Throttle
49-0553    —
1936-48  —
Clamp
9007-2  C 9967
1930-73   45”
Throttle & Spark
9008-5  D 55627-38  1930-48   Big Twin
Spark
2627-4    56626-37  1937-46  Big Twin
Spark
49-0533
1937-46
Clip
9005-4
31-0537
31-0973
31-0787
2041-7
9006-4
9007-2
9008-5
49-0533
© 2001
Bobber Patch Set.
VT No. 48-1515
Inline
Offset
