779

CLASSIC

Replica Spring Fork Shock Assembly replaces 54200-45,
includes all shock and mounting hardware for 1946-57 Spring
Fork.
VT No. Item
49-1942 Complete Kit, Black
49-1313 Shock Only
49-1954 Replica Hardware Only
49-1775 Weld On Brackets
28-1951 Bushing set (14002-45) 4 pieces
49-0241 Loom Clip (9973) V-Twin
2504-1 Loom Clip Colony

Spring Style Front Fender fits 18”, 19”,
and 21” wheels. Brackets must be fabri-
cated.
VT No. 50-0780

49-1942

49-1954

Replica Ride Control is reproduced as original to control
the action of the Spring Fork. Features steel side bars with
black control knobs. Replaces 11250-36 on 1937-48 61”, 74”
and 80”, 1940-57 45” models.

VT No. OEM

Item

Bars

49-1985 11250-36 Complete Unit

Chrome

49-1940 11250-36 Complete Unit

Stainless

49-1775

Bracket Set

Raw Steel

49-0139 13440-33 Includes the following:

13444-33 Knob, Collar and

13442-33 Spring Clip

49-1680 Strap Set Stainless

49-0140 13431-33 Friction Disc (4 pack)

49-0142 54051-33 Rubber Bushing (2 pack)

3054-16 13457-36 Ride Control Side Plate Stud Kit
13454-33

49-1678 Kit

Rebuild

49-1985

49-1940

Chrome Billet Fender Clamps will mount 50-0176 fender to
spring forks with 1” outside diameter front leg.
VT No.

Item

31-1009  Front Leg Clamp Set, Fits 1” Legs
31-0057  Brace, Zinc Plated, Fits OE Style Front Leg
50-0883  Fender

50-0883

Shock and Ride Control

Fender

Scissor Type Fork Damper fits 1936-48 Spring Forks on Big
Twin and 45”.
VT No.   Item
49-1675 Parkerized Scissor
49-1677 Chrome Scissor
49-1554  Mount Kit
49-1557  Bracket
49-1577 Parkerized Kit
49-1563 Chrome Kit

49-1554

49-1557

49-1677
Installed

49-1675

Front ³⁄₄” Axle fits 1936-57 Replica Spring Forks or OE Big
Twin with offset rockers.
VT No. Item
44-0752 Axle
44-0307 Nut

44-0752

49-1677

49-1313

Springer Fork Rod Shock Set fits 1944-48
BT. Set includes two shock units to replace
rods on front spring fork legs.
Spring fork rods are zinc plated steel.
VT No. 49-0498

49-1775
