743
CLASSIC
Oil  Line & Fitting
Stainless Hose Clamps are available
in Worm Gear type or Torro drive type.
Torro drive clamps feature pressed tooth
and raised band edges to prevent dam-
age to hose.
Worm Gear  Size
Type
35-0413
⁷⁄₃₂
”-⁵⁄₈” Fuel
35-8031
³⁄₈
”   Oil
Fuel-Oil Hose in black, black braided or
clear.
Sold in shop rolls.
Black Black Clear  Size/Length
 Braided
40-9999       —

     —
¹⁄₈
” x 25’
40-0117       —
     —
³⁄₁₆
” x 25’
40-0118       —
     —
¹⁄₄
” x 25’
40-0119       —
40-1252  ⁵⁄₁₆” x 25’
40-0254       —
     —
⁵⁄₁₆
” x 6’
40-0814       —
     —
⁵⁄₁₆
” x 6’
40-0769     —
     —
⁵⁄₁₆
” x 20’
40-0253       —
     —
³⁄₈
” x 6’
40-0120  40-0765       —
³⁄₈
” x 25’
40-0767       —
     —
³⁄₈
” x 20
     —
40-0763       —
³⁄₈
” x 10’
40-0126       —


¹⁄₂
” x 25’
35-0413
V-Twin Braided
Stainless Hose
 in
bulk length and can be
cut to length as need-
ed. Use econo-seal ends or hose clamps
to attach to fitting.
Warning: Not for use
in brake systems.
VT No.   Size  Feet
40-0202
  ¹⁄₄” 10
40-0200  ⁵⁄₁₆” 5
40-0245  ⁵⁄₁₆” 25
40-0210  ³⁄₈”
10
40-0244  ³⁄₈” 25
40-0210
40-0214
Chrome Econo-Seal Hose Ends act as
clamp and finished end when stainless
jacket rubber hose is cut. Micro clamp is
hidden under chrome end.
Smooth  Hex
Fits
Qty
40-0222  40-0213
¹⁄₄

6
40-0248     —
⁵⁄₁₆

6
40-0223  40-0214
³⁄₈

6
40-0224  40-0218
¹⁄₄

2
40-0249     —
⁵⁄₁₆

2
40-0225  40-0219
³⁄₈

2
   —

40-0220
¹³⁄₁₆
 ID
1
   —
40-0591 15mm  2
   —
40-0592 17mm  2
Chrome Oil Line Fitting Set allows use
of ³⁄₈” braided steel lines. Set has built
in compression fittings, so no need for
clamps. Reusable three piece set. ¹⁄₈”
NPT. For early TC-88.
VT No. 40-0583
40-0583
Polished
Stainless
Steel Hose
Lock
is a com-
pression fitting
that replaces
conventional
hose clamps. Feature a cleaner appear-
ance and superior sealing performance.
Pair Each Size
35-0180
35-0175
¹⁄₄
35-0181
    —
⁵⁄₁₆
35-0183*      —
⁵⁄₁₆
35-0182
    —
³⁄₈
*Note: Fits S&S Super “E” carburetor
fitting.
35-0180
Zinc Oil Hose Support Bracket.
VT No. 31-0125
31-0125
Chain Oiler Fitting replaces 60549-70
on 1970-84 FL-FX models. It attaches to
inner primary cover. Sold each.
VT No.  Type
40-0524
 Stock
40-9976  Side Hole for Extra Chain Oil
Oil Line Fitting Kit includes four cadmi-
um plated fittings for use with stock lines
when an external oil filter is used. Fittings
will work with aluminum cover oil pump
only.
VT No.
Fits
40-0505  1940-57 Rigid
40-0506  1958-64 Swingarm
40-0506
40-0524
40-9976
Cadmium Plated Straps used on 1952-
67 clutch booster cable, 1965-71 FX, FL
models oil tank feed line hose and 1958-
71 sidecar brake tube.
VT No. 2753-5
40-0223
40-0505
Replica Panhead Y Oil Line Kit for
use on stock 1963-65 heads or on
STD heads for outside oiling. Timing
cover must be drilled for oil feed to
this line.
VT No.   Item/Finish
40-0179*
Steel, Chrome
*Note: Has elbowed fittings
40-0113 Chrome
40-0129  Tin Plate
40-0128  Elbow, brass
40-0260  Elbow, zinc
12-1280  Rear Chain Oiler
40-1008  Fittings, zinc
40-0179
Chrome Y Oil Line. Updated
design allows even flow to both
hands on external oil Panheads
when installed on Shovelhead
lower ends.
VT No. 40-0606
40-0606
Panhead 1963-65
Hose Clamp
Assortment set
includes
50 clamps: 20 of ¹⁄₂”, 15
of ⁵⁄₁₆
” and 15 of ³⁄₈”, zinc
finish.
VT No. 35-0472
12-1280
