CLASSIC
Oil Tank Decals are FLH style. (5 pack except where noted)
Adhesive  Water Based  OEM
Style
48-0426       —
62535-65
H, Long
48-0427   48-1379
62535-61A  H, Lightening
    —
48-0439

Decal “V”
48-0958      —
Pair 3⁹⁄₁₆” x 1³⁄₈”
    —
48-1380 Each  3⁹⁄₁₆” x 1³⁄₈”
    —
48-0838 Each  Patent
48-0426
48-0427
Electric Start Wrap-Around Oil Tank with four quart capac-
ity, fits 4-Speed stock rigid and swingarm frames pre-1984
Big Twins, not FXR. It features built in battery box for VT No.
53-0518 battery, FXE type. 4 quarts.
Chrome Black
Item
40-0408  40-0618  Oil Tank
31-0191  Zinc
Rear Bracket
Chrome Smooth or Hex Wrap Around Oil Tank installs on
stock FX-FL swing arm frames 1965-84 and houses the stock
FXE battery, VT No. 53-0518 and allows removal of battery
without removing the tank from the frame. All fittings exit from the
bottom of the tank on 3¹⁄₂ quarts.
VT No.  Type
40-0406
 Smooth, Can only be used w/Hitachi type starter motor
40-0405 Hex Type
40-0406
40-0405
40-0405
40-0406
Installed
40-0408
FX-FL Chrome Oil Tank for 1965-84
models. Includes filler plug. Cap and filter
not included. VT No. 40-0455 kit includes
chrome tank, cap, oil filter and mount kit.
40-0455
40-0417
40-0413,
40-0417
40-0414
Chrome Edging for Oil Tank is for use on
FLH-FXE 1965-84 model, and is fastened
by stock screws. Replaces 62534-65.
VT No. 42-0506
Oil Tank Mount Kit is 1965-84 FXE-
FLH. Includes zinc plated bolts and
hardware as illustrated to mount tank to
frame and battery box.
VT No. 40-0320
48-0958
48-1379
48-1380
VT No.
Finish
Item
40-0417 Chrome
Tank
40-0834  Black
Tank (65-69 FL)
40-0626 Primer
Tank
40-0410 Black
Tank
40-0455 Chrome
Kit
40-0413*  62483-81
1981-82
40-0414** 62504-82
1982-86



will not accept internal canister
*Note: Fits up to 1985, accepts Internal Canister.
**Note: Requires battery carrier bracket 42-9912 for FX mod-
els and 42-9910 for FL models
40-0618
40-0834
Oil Tank
40-0626
Bobber Oil Tank has top mount and holds 53-0075 battery.
Chrome Black
Raw
Item
40-1423  40-1289  40-1425  1941-1957 FL, Top Mount
40-0491  40-0616  40-1429  Rear Mount
40-1289 shown
installed
