CLASSIC
Dash Kit
Two or Three Light Dash Kit is complete as illustrated.
Includes either 1:1 or 2:1 ratio speedometer and the correct five
post key switch with two keys. Order plainbase dash kit when it
is not desired to rewire harness for dash lighting. Choose prop-
er cable for each application. Can be mounted on 1947-84 FL
Big Twin models.
VT No.   Type
39-0904
3 Light Plain Base 1:1
39-0951
3 Light Plain Base without Speedometer
39-0905
2 Light Plain Base 1:1
39-0906
3 Light Plain Base 2:1
39-0907
2 Light Plain Base 2:1
39-0908
3 Light Wired Base 1:1
39-0909
2 Light Wired Base 1:1
39-0910
3 Light Wired Base 2:1
39-0911
2 Light Wired Base 2:1
33-0534
Bulb Socket, pair
V-Twin Dash Kits are available with the popular tachome-
ter-speedometer combination included. Can be wired to 1978-
up FX-FL models with a tach that is triggered by coil impulse.
See instructions for tach wiring. Wired base includes light
sockets and all hardware for installation.
VT No.
Type
Ratio
39-0915
2 lite
2:1
39-0916
3 lite
2:1
39-0917
2 lite
1:1
39-0918
3 lite
1:1
Steel Dash Panel Components
VT No.
OEM
Item


Light
39-0234
2 Light Lens Kit

2
39-0349
71300-47
Lens Holder

2
39-0115
71350-47
Lens

  2
39-0354
71310-38
Cover Plug, 1939-67
All
39-0353
71311-47
Cover Side Plate
2
39-0344
71292 62
Shield

3
39-0114
71091-59
Lens Set

3

71351-59
2 Red, 1 Blue

3
39-0910
3 Light
Dash
39-0907
2 Light
Dash
Dash Insulator and Bolt Hardware Kit is
sold in three pack, for dash rebuilding.
VT No. 32-8013
Dash Panel Mounting
Stud and Center Screw
features chrome domed
center screw, stud and
lock nuts to mount two light
steel dashes to 1947-67.
VT No.
Item
7716-2
Kit, Colony
39-0123  Kit, V-Twin
39-0226  Center Stud
8483-2
Center Screw only
39-0155  Lock Tab only
Two and Three Light Dash Panels. Two light fits 1947-61 Big
Twin and 45 models. Three light type fits 1962-67 Big Twin.
VT No.
Type
Item
Finish
39-0111 2-Light  Dash
Chrome
39-0953 2-Light  Dash
Raw
39-0952 3-Light  Dash
Raw
39-0110 3-Light  Dash
Chrome
28-0542 Strip

Rubber
39-0144  Without key switch hole  Chrome
39-0459  Rail Kit
Deco
Chrome
V-Twin Original Dash Kits First Offered in 1984!
39-0111
39-0110
39-0144
Chrome Dash with 91.5 mm speedometer hole accepts elec-
tronic speedometer from XL-FXD models.
VT No.   Type
39-0892
Smooth
39-0893 3-Light
39-0893
39-0892
39-0344
39-0115
39-0114
32-8013
39-0123
39-0915
39-0918
39-0908
7716-2
