CLASSIC
Linkert Carburetor
35-0501
35-0552
35-9175
35-0563
35-0045
35-0046
Linkert Complete Carburetor Hardware Assembly Kit includes all
parts except body. Kit includes parts pictured.
VT No.  Model Size  Rebuild

Service
35
-0079  M74  1¹⁄₂”  60-0148
35
-0078  M88  1¹⁄₄”  60-0188
35
-0342  M88
60
-0188
35
-0263  M88
35
-0081  M88I  1¹⁄₄”  60-0147
35
-0045  M51L  1¹⁄₄”  60-0144
35
-0046  M51L
60
-0143
35
-0624  M51L
35
-0049  M35  1¹⁄₂”  60-0146
35
-0190  M18  1”
60
-0145
35
-0038  M18
35
-1941  M41 1⁵⁄₁₆”
60
-0188
35-0079
Linkert Overhaul Kit is complete with hardware. Includes needle and
seat, float, bushings, springs, float pin and gaskets for 1933-65 models.
VT No.
Item
35-0563  Kit with cork float,
35-0501  Kit with Linkert M foam float
35-0552  Kit with black foam float
35-0666  Kit with foam float
35-9175  Kit with brass float
35-0790  Kit with nitrophyl float
35-0873  Kit with 18 pieces; black float, bushings, springs, float pin,
stainless steel needle, brass seat and a 3-bolt insulator spacer.
35-9194  Kit includes throttle shaft brass float, needle and seat, float,
bushings, springs, float pin, gasket, carburetor bowl large nut with stud,
lock washer luck nut, and copper filled seal washer.
35-0553  Kit includes 1 1/2" throttle shaft, float bowl nut, and float
lever.
35-0944  Linkert Carburetor Gasket Kit
35-8009  Linkert kit does not have float.
Gasket Kit Onlyl
14-0926  Gasket for Above
15-0622  Gasket Kit, 3 and 4 Bolt
15-0545  Gasket Set
15-0420  Gasket Set, 3 Bolt
15-1102  As Above, James
15-0629  Gasket Kit, 3 Bolt
15-0304  Bowl Gasket, 1936-51, 5 pack
15-0321  Bowl Gasket 1952-65
15-0232  Bowl Nut Gasket
15-0262 Spacer
15-0538  Spacer Kit
15-1386  Spacer James
35-0341  Complete Screw Kit Only
15-0545
35-0790
35-0078
35-0666
35-0049
35-0190
Linkert Drill Service Kit as original. Full
instructions for this on our website. Tool kit
with drill pivots. Drill bit sizes include #55
(1.3mm), #53 (1.5mm), #56 (1.2mm), #42
(2.3mm), #72 (0.6mm). The #55 drill bit is
used by two different length handles. Slot
tool blade sizes include .017” and .009” for
all carburetors.
VT No. 16-0563
Linkert Rebuild Kits
VT No.  Size
OEM
35-7133  1"
27133-36
35-7132  1 1/4"
27132-36
35-7134  1 1/2"
27134-41
1941-65 Overhead Valve Big Twin Carburetor
Support Brackets are replica for Linkert carburetors.
Replace 27431-41.
VT No.  Year
Finish
31-0194 1941-53 Chrome
9009-5  1941-53 Parkerized
9010-5  1954-65 Parkerized (Pictured)
9010-5
Linkert Machining Services. Machine
shop services done on Linkert carb bod-
ies. Float bowl restoration.
VT No. 60-0195
Throttle Bore Truing allows installation
of oversize throttle door.Body will be
machined to fit correct oversize door.
VT No. 60-0345
Throttle Bore Honing Service removes
minor imperfections for a smooth carb
bore.
VT No. 60-0122
Parkerized Carburetor Support Brackets
are replica for Linkert carburetors.
VT No. #  OEM
Year/Model
9011-5 A 1110-33  1930-38 SV Big Twin
9012-5 B 1110-39  1939-48 SV Big Twin
9013-4  C 27432-36 1936-55 45
Watch Our Video!
http://www.youtube.
com/user/TeddCycle
Taps used on Linkert.
Taps for Body are:
1. #10-32
2. #12-24
3. 1/4 -40
4. 5/16-18
5. 5/16-32
Dash Mounted Choke Control
