2-Brush Generator Components are available separately.
VT No.
OEM
Item
32-0164
30012-58
Bolt (2)
32-0234
30426-58
Brush Set
32-0231
29913-82
Brush Set, Hitachi
12-0581
7634
Terminal Nut
12-2120
30280-58
Pole Screw
32-0209
30350-58
6 Volt Brush Holder
32-0210
30450-66
12 Volt Brush Holder
13-0117
30453-58
Brush Spring, 10 pack
12-0303
9007
Gear End Bearing
12-0304
9007
Gear End Bearing (Open)
10-2553
30148-58
Brush End Cover Bushing
12-0319
9064
Brush End Cover Bearing
12-0902
11004
Front End Retaining Ring
14-0112
30145-46A
Shaft End Seal, 1958-81
Generator 2-Brush Set fits 1958-69
Replaces 30426-58.
VT No. 32-0234
Generator Rebuild Kit. Complete
as shown, all small parts necessary
for rebuilding a 6 or 12 volt, 2-brush
generator.
VT No. 32-0431
Generator Terminal Nuts replace 7634, on all
generators 1930-up, (10 pack).
VT No.
Type
12-0572  Brass
12-0581  Steel with star washer
2-Brush Generator Terminal Kits include
nuts and insulators. Fits 1958-69.
VT No. 2127-11
Generator 2-Brush Hardware Kits include
gaskets and replacement hardware as shown.
VT No. 32-0227
Generator Parts.
VT No.   Item
Years
32-0217  Oil  Deflector 1958-81
32-0219  Washer 1958-69
32-0219
Replica 2-Brush Field Coils feature warp-
free laminates and heavy copper core wind-
ing. Set is matched pair with lead.
VT No.
OEM
Type
Volt
32-0229   30201-58A  58/61
6
32-7599
30201-65
65
12
Replica Generator Armatures feature heavy copper wind-
ings on precision shafts with solid copper commutator.
*Note:
Replica style.
VT No.  OEM
Volt
Model
Brand
32-0225  30851-61  6
1961-64 FL
Accel
32-0226  30851-58   6
1958-60 FL
V-Twin
32-0222* 30851-65A  12
1965-69  FL
V-Twin
2-Brush
Generator Repair
Chrome Generator Covers.
VT No.
Model  Years  Type
42-0414   2-Brush  1958-81 End
42-0522  Hitachi  1982-84 End
42-0406  2-Brush  1958-81 Body Wrap
42-0406
42-0522
42-0414
2-Brush Generator Gear Kit is available
as complete kit. Kits include13-tooth gear,
oil deflector, washer hex nut. Fits 1958-69
74 FL.
VT No.
Item
Fits
32-0204  Kit
BT
32-1363  Gear
Servi
32-0220
Gear
BT
32-1245
Spacer   5 pack
12-0581
Generator End Brush Band
for 1966-80 2-Brush generators
replaces 30475-66 with bolt.
VT No.   Finish
32-0199
Chrome
32-0200  Black
Use HeliCoil 16-0920
kit to convert 12 volt
generators with ⁵⁄₁₆ - 24
thread to ¹⁄₄ - 24 thread
to accept early mount
bolt set.
Tech Tip: 12 V Upgrade
Generator Mounting Screws for Big Twin
1958-69 with Hex.
Chrome Cadmium    Brush
Style
8153-2  8154-2
 2
Stock
7113-2
  2
Acorn
8754-2
  2
Allen
Generator Case Mount Gasket fits 1958-
69. 2-brush.
VT No.   U/M
15-0150
10
15-0565  2
32-0204
32-0217
7113-2
32-0199
32-0200
32-0226
32-0222
