671

CLASSIC

Volt Tech Molded Dual Fire Coil features black late shape
with bobbin type windings.
VT No. Year
32-7572 1965-79
32-7573 1980-82

Accel Power Pulse 12V Dual Fire Coil provides longer spark
duration with a greater KV rating and faster rise time than stock
coil. Molded in epoxy. for 1965-83.
VT No. Epoxy Finish
32-0130 Yellow
32-1064 Black

Blue Streak 45,000 Volt Dual Fire Coils provide more spark
and energy than stock coil and the higher voltage eliminates
spark deterioration at peak RPM.
VT No. Years

Type

Ohms

32-0171 1980-99 Electronic 2.7
32-0172 1965-79 Point

4.6

32-0172

32-0514

32-0513

32-0171

32-7573

32-7572

Black Andrews Black Dual Fire Coil
produces more voltage than stock coils.
VT No.   Ohm  Year
32-0709  4.8 1965-80
32-0712  2.8 1981-99

32-0709

Replica 1961-64 Big Twin 6 Volt
Dual Coil replaces 31604-61. Sold
each.
VT No. 32-0131

Volt Tech Stock Replica Dual Fire Coils are factory replace-
ment quality to fit stock brackets.
VT No.

Year

Volt

Color

32-0711 Pre1965

Rust

32-0128 1965-79 12V

Black

32-1268 1965-80

12 V

Red (4.8 ohm)

32-0129 1980-83

12V

Black (2.8 ohm)

Note: 32-0129 for electronic ignition.

Warranty

All Electrical Components sold as individual pieces or in kits are covered under
our warranty “Replacement Only” Provision. All electrical related item part num-
bers begin with a 32 prefix. No credit will be issued for these items as they are
exchange only.

Ignition Coil

32-0711

32-0129

80 KV Dual Fire Coil for 1965-99
mounts to stock locations.
VT No. 32-0095

VT No. OEM

Year

32-0513 31609-65A 1965-79
32-0514 31609-80 1980-83

Chrome Stock
Style Dual Fire
Coils bolt to orig-
inal brackets for
exact fit.

Single Fire: Just the spark plug for the piston that is in its compression stroke will be fired. The other piston, being in its overlap position will
not be ignited.
Dual Fire: Both spark plugs are fired simultaneously at the time only one piston is in its compression stroke.
This is the way the stock motor works on preTC-88 motors.
Single Plug: One spark plug in each head. Total of 2 spark plugs in one engine.
Dual Plug: Two spark plugs in each head. Total of 4 spark plugs in one engine.

32-0128

32-1268

32-0130

Accel H.V. Dual Fire Super Coil bolt on for
points ignition systems. High-tech molding for
1965-99 with 4.7 ohms. Yellow.
VT No. 32-7771

Accel High Energy Dual Fire Coil is a very high KV energy
output requires that it be used with our extreme service 8.8mm
silicone racing wires. Each coil is complete with two 8.8mm
wire leads and appropriate chrome brackets.

Coil

Accel Single Fire Super Coil fea-
tures ultra fast coil rise time with
voltage output 45% higher than
stock & 3.0 ohms of primary resis-
tance. Mounts to stock coil bracket
& fits under stock coil covers. Fits
all Twins except TC-88.
VT No. Type
32-0090 Yellow
32-7802 Chrome

32-7536

32-7771

32-0132

VT No.

Item

32-0132 Kit 1965-87
32-7536 Wires only

32-0090

32-7802

32-1064
