CLASSIC
Shock Stud
Shock Stud Washer 10 pack.
VT No.
OEM
Type
Finish
54-0418 54544-65  ⁵⁄₈” Hole Cup
Chrome
54-0419 54543-65  ³⁄₈” Hole Cup
Chrome
54-0420 54545-65  ¹⁄₂” Hole Cup
Chrome
54-0421 6718
¹⁄₂
” Hole x 1” Flat
Chrome
54-0424 6722B
⁵⁄₈
” Hole x 1.3” Flat
Zinc
54-0432 6415B
³⁄₈
” Hole x 1.25” Flat
Zinc
Shock Stud Conversion allows use of shocks with ¹⁄₂” holes with
steel inserts. Simply press out stock bushing and sleeve, replace
with the 2-piece style. Fits the ⁵⁄₈” diameter studs on many models.
Use a ⁵⁄₈” cup washer for final assembly. Set of 8 rubbers.
VT No.
Item
28-0133
Rubber Bushing
54-0418
5/8 Cup Washers, 10 pack
Nyloc shock stud nut is
⁵⁄₈
-18 UNC thread, replaces 7993.
VT No.
Finish
Qty
54-0422  Zinc   10
54-0447  Chrome 4
Shock Bushings fit 1958-84 Big Twin,
pack of 10. Replaces OEM 85210-42A.
VT No.   Item
28-0220
Bushings
37-0431  Steel Sleeves
Replacement Hardware fits stock or aftermarket shocks 1967
later, top clip type.
VT No.  OEM
Item
U/M
54-0204  54558-73  Rotating Cam
Pair
54-0203  54559-73  Cam Sleeve
Pair
54-0429  54700-67  Upper Cover
Pair
54-0204
54-0203
Shock Stud Kits feature all pieces for upper and lower posi-
tions. Including washers, nuts and lockwashers as necessary.
Studs and bolts are zinc plated. Outer nuts and washers are
chrome.
VT No.  Year
54-0466
1958-64 *Note: with chrome studs.
54-0464 1958-64
54-0463 1965-66
54-0462 1967-72
54-0465  1973-84
54-0462
Stock Stud Spacers replace
5960W on 1965-85 FLH when rear
frame bars are not used. Zinc plat-
ed, pair.
VT No. 54-0425
Rear Shock Studs, with cup washers. Each kit includes two
studs and four chrome plated cup washers. Cup washers and
lock nuts may be purchased separately.
Upper Pair
Chrome Zinc
OEM
Fits
54-0445  54-0408  54515-58A
1958-64 FL ³⁄₈” thread
     —
54-0409  54515-65
1965-66 FL
54-0440  54-0410  54515-67
1967-72 FL-FX
54-0442  54-0416  54515-73
1973-84 FX
Lower Pair
54-0446  54-0411
  54517-58
1958-64 FL
     —
54-0413  54517-65
1965-66 FL
54-0441  54-0412  54517-67
1967-72 FL-FX
     —
54-0401  3958
1973-84 FL-FX
28-0133
54-0418
54-0429
54-0408
54-0412
54-0410
54-0401
54-0466
54-0464
54-0465
54-0463
