V-Twin Mfg
TM
Brake Rotors feature fine finish ground surface. Available with or without
holes in steel unless construction is noted as stainless. Exactly interchangeable with stock
rotors. Order bolt set separately.
Replica Steel Brake Rotor
23-0312
23-0313
23-0309
23-0298
Brake Rotor Spacers provide offset when required, with ⁷⁄₁₆”
bolt holes. Each spacer measures 2¹⁄₁₆” inner diameter with
4⁵⁄₁₆” outside diameter For 1980-99.
VT No.
Thick Material
23-0320* ¹⁄₁₆” Steel
19-0128 ³⁄₁₆” Steel
19-0452 ³⁄₁₆” Billet
19-0413 ¹⁄₄” Steel
19-0414 ⁵⁄₁₆” Steel
*Note: Use when installing flat brake rotor on 1973-75 Big
Twin.
19-0414
Polished 10” Brake Rotors.
Note: VT No. 23-0848 has chrome center. All brake rotors
have 2” inner diameter center hole.
VT No. Fits Style
23-0847 Rear, Left 1973-80 FL-FX, Center hole is 2”
23-0848 Rear, Left 1973-80 FL-FX, Center hole is 1.98”
23-0854 Front, Right 1973-84 FL
23-0849 Rear, Right
Brake Rotor Bolt Spacers will adapt 1973-up FX-FL rear
hubs to accept brake rotors for front fork use, VT No. 44-0528
fits dual disc type 1980-83 FXWG.
VT No.
Outside Diameter
Inner Diameter
44-0528 ³⁄₈”
⁵⁄₁₆
”
44-0511 ⁷⁄₁₆”
³⁄₈
”
44-0554 ⁷⁄₁₆”
⁵⁄₁₆
”
44-0528
44-0554
44-0511
Drilled
Plain
OEM
Dia.
Bolt Kit
Fits
FRONT
23-0304
23-0305
41813-79
10”
8738-10
Cast or Wire
1972-84 FLH
1973 only FX
23-0309
23-0310
41806-72B
10”
8738-10
Cast or Wire
1972-84 FLH, 1973 only FX
with built in offset
23-0311
23-0312
44137-77A
10”
8758-10
Cast or Wire
1977-83 All FX Cast or Wire Wheel
1982-83 FXR Cast or Wire Wheel,
2
3
/
8
” Inner Diameter Center Hole
23-0298
23-0299
44137-77A
10”
8831-10
Wire
FXWG 1980-83 Dual Disc Wire Wheel
with 2” Inner Diameter Center Hole. Requires 2 Bolt Sets.
23-0370
—
44210-79
10”
8792-5
1979-83 FLT
23-0371
—
44210-79
10”
8792-5
As Above Stainless
REAR
23-0304
23-0305
41791-79
10”
8738-10
1973-80 All FL
1978-80 All FX’s Cast or Wire
23-0309
23-0310
41806-72B
10”
8738-10
1973-78 All Big Twin with built in offset
23-0307
23-0308
41791-79
11.5” 8791-10
1981-92 FXST-FXR Cast or Wire
23-0297
23-0313
40909-81A
12”
8791-10
1981-84 FLH Cast or Wire .390” thick.
23-0297
23-0313
40939-79A
12”
8792-5
1979-85 FLT
