380

Air Cleaner Breather Only includes cone, element and elbow
as shown. Fits 1993-2007 CV in the horizontal position.
VT No.

Type

34-0770 Spike
34-0771 Funnel
34-0274

Filter Only

34-0771

34-0771
Installed

34-0451

34-0670

34-0670 installed with
34-0693 adapter

34-0451 with
34-0693 adapter

34-0670

34-0671

Air Cones

Wind Funnel Air Filter Kit includes bracket with integral breath-
er which will mount the funnel in a forward horizontal position.
Order with or without turbo fan.
VT No.   Type
34-0488  Fan (1993-2007) with CV carburetor
34-1207  Without

34-0488

Installed

Chrome Panzer Air Cone can be installed on C.V. or S&S
Super E carburetors. Cone can be mounted in either vertical
or horizontal position. Includes air filter. Order routing bracket
separately.
VT No. 34-0772

Cycovator Taper Forward
Mount Air Cleaner Only
fits 1993-07 CV FLT except
1995-01 EFI, 1993-2007
FXST, FLST, FXD, 1993-94
FXR.
VT No. 34-0773

34-1197

Turbo Funnel will mount on
CV carburetor bolt pattern in
a forward horizontal position.
Order adapter plate 34-0693
to place in upright vertical
position. Fits 1993-2007 Big
Twin CV-Delphi-EFI
VT No. 34-1197

• Super Spiral runs ups to

10,000 RPM to match your

high revving engine.

• Help provide a better fuel

mixture and combustion

34-0773

34-0772

Air Cleaner Breather includes steel bracket with breather
bolts and tapered filter element with chrome 90° intake tube
to face forward on CV carburetors. Order adapter to face for-
ward or upward on S&S models. Use 34-0670 with 34-0693
adapter. For 1993-07 models.
VT No. Item

Style

34-0670 Spike

Forward

34-0451 Funnel

Forward

34-0673 S&S Adapter

34-0693  CV Vertical Adapter
34-0671  Filter Only (Spike)
34-0274  Filter Only (Funnel)

CV Air Cleaner Cone System features cone and integral
breather mount bracket for vertical or forward mounting. Order
adapter plates for vertical applications.
VT No.

Carburetor Type

34-0775 S&S “E”
34-1211 1993-07 CV, Delphi EFI

34-1211

34-0775

34-1211

34-0451 Installed

34-0770

Important Note:

Some items on this page may be emission-related parts subject to California or other emission control laws. Please see

note for important information regarding emission control regulatory compliance and warranty information.
