341
BIG TWIN
Chrome Manifold Cover fits 2004-up
FXD, 2001-up Softail and 2002-16 FLT
replaces 27483-07.
VT No. Item
34-0100 Kit
15-1527 Gasket
Intake Flange Set fits elec-
tronic fuel injection models
2007-up.
VT No. 34-1188
Induction Flange Set will adapt
34-0181 to 34-0705 Sifton breather
bracket.
VT No. 34-1523
ThunderJet
®
Electronic Fuel Injection Manifold.
VT No. Description
35-0153 W/ 5.013”-5.016” Long Cylinders fit S&S
124” Kit and Jims 116” Kit
35-0154 W/4.975-4.980” Long Cylinders fits 117” Kit
35-0155 With 5.037” Long Cylinders fits 120” Kit
ThunderJet
®
EFI Components
Magneti Marelli Fuel Injection to
Carburetor Petcock Conversion Fitting Set.
Converts all 1995-01 Big Twins equipped with
Magneti Marelli Fuel Injection System to car-
buretor system. Can be used with any 22mm
petcock. Fits 1995-up FLT models.
VT No. 35-0751
Billet Flange Set for use when install-
ing larger throttle bodies for electronic
fuel injection.
VT No. 35-0787
35-1078
Electronic Fuel Injection Gaskets.
VT No. OEM
Type
Year
15-1536 29368-99 Induction 1999-01
15-1200 29368-99 Induction 1999-01 (James)
15-1537 29463-99 Air Filter 1999-07
15-1297 29718-08 As Above James
15-1568 29645-08 Air Filter 2008-17
15-1536
15-1537
15-1568
15-1356
Fuel Filters.
VT No. Fits
Item
35-6105 2008-up FXST, FLST, 2004-up FXD Fuel Filter
35-6104 2002-07 FXST, FLST
Fuel Filter
35-6108 2000-07 FXST, FLST Line
35-6108
James Induction Module Gasket and O-Ring Kit fits1999-up
FXST, FLST, FXD, 1999-16 FLT.
VT No. 15-1356
15-1200
EFI Replacement Fuel Pump Kit for the OEM pump and in-
cludes pump hose and hardware.
VT No. Fits
35-1075 1998-99 FLT
35-1076 2000-01 FLT
35-1077 2008-15 FLT
35-1078 2004-17 FXD
2008-17 FXST, FLST, FLST
35-1077
35-1076
35-1075
Chrome Fuel Fitting for EFI models fits
2003-up FLT, 2002-17 FXST, FLST and
2004-07 FXD.
VT No. 35-0950
35-6104
35-6105
15-1297
35-0153
Important Note:
Some items on this page may be emission-related parts subject to California or other emission control laws. Please see
note for important information regarding emission control regulatory compliance and warranty information.
35-0154
35-0155
FLT EFI Fuel Line Kit replaces the
fuel line from the gas tank to the fuel
rail. Fits 2012-16.
VT No. 35-6111
