335

BIG TWIN

Dyna Electric Tachometer Adapter Kit must be
used with Dyna ‘S’ single fire ignition is installed
on any twins when electric tachometer is used.
VT No. 32-7799

Dyna ‘S’
Hi-Performance
Ignition System is
self contained, fits
behind ignition cover,
uses magnetic rotor
with the original spark
advancer, so factory
advance curve is

maintained. Improves performance, extends spark plug life,
eliminates points and condensers.

Note: For dual plugged

heads, on 1980-up use advance mechanism, VT No. 32-7510
VT No. 32-7778 (DS6-1)

Dyna ‘S’
Single Fire
Ignition has
the features
of the Dyna
’S’, but fires
front and
rear cylinders
independently

of each other which allows accurate timing of each cylinder.
Stock ignition systems fire both cylinders at the same time
which has the wasted sparks on the exhaust stroke. This
eliminates this inherent problem. For use with either dual or
single plug heads. On 1980-up models, use VT No. 32-7510
Advance assembly.
VT No. 32-7777 (DS6-2)

Replacement Rotor for Dyna Ignitions.
VT No.

Fits

32-9300 DS-6-1
32-9301 DS-6-2

Dyna S Performance Ignition Systems.
Available in dual or single fire for street
applications only. Each kit includes sensor
plate assembly and correct coil for each
application. Single plug only. 1980-up
applications require 32-7510 advance
mechanism.
VT No. #

Type

32-0800 DSK-6-2 Single Fire
32-0801 SDK-6-1 Dual Fire

Ignition

Dyna 2000i Digital Ignition available as a module only or com-
plete kits that include correct coil. Features include single or
dual fire operation, 8 advance curves, built in tach driver, adjust-
able RPM limit from 6000 to 7500 and easy static timing with
built in timing indicator. Fits all 1970-98 carbureted models and
requires 1983-up sensor cup for 1982 and earlier applications.
Advanced Programming Software allows the mechanic or tuner
the ability to fine tune 2000I Ignition but requires adapter.
VT No.

Item

Plug

Fire

Coil

32-9151

Kit

Single

DC3-1

32-9152

Kit

Dual

Single

DC1-1

32-9153

Kit

Dual

DC2-1

32-9155

Kit

Single

DC6-5

32-9159

Module Only

32-9087

Sensor Cup

32-9052

Cup Screw, 10 pack

32-9120

Advanced Programming Software for

Above Ignitions

32-9151

32-9152

32-9153

32-7789

32-7792

32-7790

K.V. Recommends the following coils for Dyna Ignitions:
DS6-1 Ignition VT No. 32-7778
Street, Single plugs use DC-7 or DC-8
Race, Single plugs use DC-1 or DC-6
Street/Race Dual plugs use 2 DC-2 or DC-5, wired in series
DS6-2 Ignition VT No. 32-7777
Race, Single plugs use 2 DC-3
Street, Dual plugs use 2 DC-7 or DC-8
Race, Dual plugs use 2 DC-1 or 2 DC-6
Street, Single plug uses 2 DC10-1

Dyna Coils generate 35,000 volts and work with all points
ignitions as well as aftermarket or factory electronic ignitions.
Note: 32-7792 is electronic, 32-7793 is for points ignition.
VT No. #

Volt Ohm Dyna

Type

U/M

32-7789 A

12V 3

DC-1

Angle, Dual Pair

32-7790 A

6V 1

DC-2

Angle, Dual Pair

Use 2 for dual plug heads
32-7792 C

12V 3

DC-6

Stock, Dual Each

32-7793* C

12V 5

DC-7

Stock, Dual Each

32-8055 B

12V 3

DC-3

Angle, Single Pair

32-8086 A

12V 5

DC-8

Angle, Dual Pair

32-9035 B

12V 5

DC-10-1 Angle, Single Pair

*Note: Use two for single fire ignition.

32-8055

32-7793

32-8086

32-9035

Important Note:

Some items on this page may be emission-related parts subject to California or other emission control laws. Please

see note for important information regarding emission control regulatory compliance and warranty information.
