BIG TWIN
Fork Damper Tube
Fork Damper Tubes less hardware. Sold
as pairs unless noted as each.
VT No. Year
Model
39mm
24-0647 1987-93 FXR
24-0476 1995-17 FXD
24-0676 1987-94 FXR Nylon Ring
41mm
24-0455 1984-99 FXST
24-0678 1986-99 FLST
24-0180 1983-96 FLT
24-0148 1977-84 FL
Big Twin Nylon Ring (4 pieces)
24-0469 2000-07 FXST
24-0489 2000-06 FLST
24-0490 1997-08 FLT
49mm
24-9024* 2006-16 FXDWG
24-2059* 2006-16 FXD, FXB
24-9025* 2014-16 FLT
24-2058* 2017-up FLT
24-1333* 2008-16 FXDF
*Note: Sold each
Fork Damper Sets will lower front forks
on Softail models 2.5”. Use with stock fork
springs.
VT No. Year
24-0528 1984-99
24-0529 2000-06
Fork Bushings.
VT No. Size
Fits
24-0450 35mm 1984-87 FXR Upper
24-0451 35mm 1984-87 FXR Lower
24-0182 39mm 1988-94 FXR Upper
24-0181 39mm 1988-94 FXR Lower
24-0449 41mm 1984-10 FXST, 1986-17 FLST,
1984-13 FLT Upper
24-0097 41mm Same as Above FXST-FLT Lower
41mm Damper Valve Set fits 2000-up
FXST models. Allows accurate damping
of oil flow.
VT No. 24-0361
Lower Damper Tube Stop, sold in pairs.
VT No. Fits
24-0258 1984-99 FXST-FLT
1995-96 FXDWG
24-0491 1997-17 FXDWG
2000-up FXST-FLT
24-0466 1988-94 FXR
24-0375 1991-05 FXD
24-1391* 2016-17 FXD
*Note: Sold each.
24-0258
Fork Internals
1984-99 Softail
Internal Fork
Hardware Kits include
springs, damper kits,
seal kit, washer, inner
cap tube plug and top
taper fork cap.
VT No. 24-0767
Fork Damper Tube Kit includes for two sides, damper tubes
with rings, screws and washers, lower stops, slider seal wash-
ers and retaining rings. For Showa forks.
VT No.
Fits
Size (mm)
24-0470 1984-99 FXST-FXWG 41
24-1270 2000-07 FXST
41
24-0471 1986-99 FLST
41
24-0488 1983-96 FLT
41
24-0468 1987-93 FXR
39
24-0496 1995-17 FXD
39
24-1334 2006-17 FXD
49
24-0470
24-0468
Chrome Fork Slider Bottom Cap Stud and Nut
Kit includes locknuts and studs. Fits 1973-up
Showa and Kayaba.
VT No. 8826-6
Fork Drain Screws are supplied with washers. Sold as pair.
VT No. Use
9910-4 1973-84 Showa
24-0010 1976-05 Showa
9758-2 1977-up FLH, 1980-up FXWG
24-0011 As Above
24-0097
Fork Damper Valve fits 2009-up. OEM#
46209-09. 41 mm.
VT No. 24-1413
24-0010
9910-4
24-0011
9758-2
24-0450
24-0148
24-1391
Lowering
24-0496
24-1334
24-1270
24-0471
