289
BIG TWIN
Replica 39mm
Triple Tree
Narrow Glide Conversion Kit to fit FXD-XL 39mm models.
Includes upper and lower triple trees, stem, stem nut, fork
stops, axle, axle spacers and fender spacers. Kit can be used
with 1984-99 FXST/FXDWG 41mm fork leg assemblies and
1984-99 narrow glide 19” or 21” wheel assembly with aluminum
hub and front fender. Accepts 11.5” disc and caliper (custom
brakes may cause interference with laced wheels). Measures
4
15
/
16
” between fender mounts and is for front wheel speedom-
eter operation, replace left side axle spacer with speedo drive
unit.
VT No. Item
24-0958 Kit
36-2450 Speedometer Drive
Triple Tree Sets include upper and lower trees to fit 39mm
fork tubes as stock on 1990-05 FXD models.
VT No. Item
Finish
24-1392 Triple Tree Set Chrome
24-1652 Triple Tree Set Polish
24-0859 Lower Tree
Polish
24-0864 Lower Tree
Chrome
24-0865 Top Tree
Chrome
24-1331 Top Tree
Polish
37-0865 Bolt Set
12-0384 Bearing Set
24-0114 Dust Covers
24-0089 Bearing & Seal Set
39mm Chrome Fork Stem Nut Cover Three Piece Set fits
over stock stem nut. 37-9073 includes 2 fork tube cap covers
and 1 stem nut cover for 1987-up FXRS-SP, 1988-90 FXLR,
1988-90 FXR.
VT No. Style
37-9073 Flat Top
37-9520 Flat Top with Grooves
24-1278 Dome Top
24-1296 Pointed Top
Lower Fork Stem Retaining Ring
for 1986-up all models.
VT No. 12-0979
12-0384
37-9073
24-1278
37-9520
24-1296
24-1392
24-1652
24-0859
24-0864
24-0865
24-0114
24-0089
39mm Steering Stabilizer Kit
includes brackets and adjustable
round body dampener piston. Fits
1991-05 FXD.
VT No. 24-0198
41mm Narrow Triple Tree Kit includes 1" stem, trees are
same width center to center as a 39mm XL/FXD fork.
VT No. Item
24-1275 Fork
24-1441 Tree Set
24-1553 Top Tee
24-1554 Lower Tee
24-1863 Fork Stem
24-1860 Stem Nut Set
24-0958
24-1275
24-1441
