BIG TWIN
Fork for FLST 41mm
VT No. Assembly
Sliders
Disc
24-9951 Complete
Polish
Single
24-0515 Complete
Chrome
Single
24-2120 Complete
Chrome Dual
Dual Disc Fork Assembly accepts right and left 1984-88 style calipers to fit 11.5” discs. This combination gives the ultimate in
stopping power for 1948-84 FX-FL, 1986-99 FXST-FLST. Overall length is 31”.The basic kit includes
• FXST or FLH Tree Set
• 24-0518 DD Leg Assembly
• 24-0776 Fork Install Kit
VT No. Tree Type
24-2136 FXST
24-0514* FLH
*Note: Use wheels 52-0848/52-0849
Note: All related parts are available separately.
Item
VT No.
• 16” x 3 Wheel
52-0131
• Fender
50-0764
• Brake Discs (2)
23-0300
• Discs Bolts (2)
8794-10
• Gator Boots
28-0439
• Caliper Set
23-2226
• Inner Tube (SV)
46-0115
Choice of Triple Trees:
VT No.
Type
Fits
24-0000
Softail —
24-0719
“D” —
24-0800
FLH Cowl
24-2136
24-2136
VT No. Type
Caliper
Slider
Fat Kid Style
24-2019 Kit
Black
Polish
24-2020 Kit
Chrome
Chrome
FLST Style
24-2021 Kit
Black
Polish
24-2022 Kit
Chrome
Chrome
24-2019 Installed
24-2019
Installed
Fork Assembly for FLST
Chrome Fork Assembly for 2000-
06 FLSTF, FLSTC models, with 32°
frame rake. Kit includes fork assem-
bly, triple trees with bearings, dust
shields and hardware.
VT No. Item
24-0579 W/Chrome Lower Tree
24-0530 W/Black Lower Tree
24-9951
FLST Style Complete
Front End Assembly
includes the complete
fork kit with the addition
of the five piece chrome
fork cover set, 7” head-
lamp and bracket, 16”
chrome wheel, speed-
ometer drive, chrome
caliper, 11.5” drilled disc
and fat kid style or FLST
style fender.
24-2021
FLST Fork Assembly is 1986-99 Replica style featuring a chrome top tree, black
lower stem with chrome or polished lower sliders with hard chrome fork tubes and
internals installed to accept 11.5” disc. Includes neck bearings, top nut and axle
kit. Unit accepts 5 piece chrome tin fork cover set 24-9959 for the authentic look.
Order fender, wheel, and tin set separately. Fits 1949-84 FLH, 1971-84 FXE and
1985-99 Softail models. Units are 3113/16” long overall length from top tree to axle
position.
Components
VT No. Finish Item
24-9959 Chrome Five Piece Cover Set
52-0696
16” Wheel with chrome spokes
50-1075 Raw
Fender without trim holes
50-0764 Raw
Fat Kid Fender
23-3061 Black
Left side, black caliper
23-3082 Chrome Left side, chrome caliper
24-9995 Polish
Right and Left Slider Assembly
24-0511 Chrome As Above
50-0764
