277
BIG TWIN
Dyna Series
Year
Model
Front
Type
Rear
Type
1991
FXDB Sturgis
9
23-8836*
46
1992
FXDB Daytona
23-8749* 26, 28, 45 23-8836*
46
1992
FXDC Custom
23-8749* 26, 28, 45 23-8836*
46
2005
FXDC Custom
—
23-8833
2006-07 FXDCI Custom
23-8769
—
1992-99 FXDL Low Rider
23-8749* 26, 28, 45 23-8836*
46
2000-05 FXDL Low Rider
—
26, 28, 45 23-8833*
2006-07 FXDL Low Rider
—
—
1993-99 FXDWG Wide Glide
—
9
23-8836*
46
2000-05 FXDWG Wide Glide
—
9
23-8833
2006-07 FXDWG Wide Glide
23-8766
—
1994-99 FXDS Convertible
23-8749
26, 28, 45 23-8836*
2000-03 FXDS Convertible
23-8749
26, 28, 45 23-8833*
1995-99 FXD Super Glide
—
23-8836*
46
As Above +4” Ext
23-8983
30
23-8836
46
2000-05 FXD Super Glide
—
23-8833*
2006-07 FXDI Super Glide
—
—
1999-05 FXDX Super Glide Sport
23-8836*
23-8833*
2000-06 FXSTD
—
—
Upper Line Only
VT No.
Year/Model
Length
Type
—
1992-02 FXDL-FXDS
261/4” 10mm
25
Upper Line Only
FX Series
Year
Model
Front
Type
Rear
Type
1984-85 FXE-FXEF
23-8722* 9
23-8810
2
1984-87 FXS-FXRS-FXRDG-FXRC 23-8722* 9
23-8813*
3
1984-85 FXSB
—
23-8810
2
1984-86 FXWG
—
23-8810
2
As Above +2” Ext
—
9
23-8810
2
As Above +4” Ext
—
9
23-8810
2
As Above +6” Ext
—
9
23-8810
2
1985-86 FXRS Sport
—
12, 28, 45 23-8813
3
1987-93 FXRS Sport
—
26, 45
23-8846*
46
1987-94 FXLR
—
9
23-8846*
46
1988-92 FXRT Sport
—
26, 28, 45 23-8846*
46
1988-92 FXRT Sport Glide
—
9
23-8846*
46
1988-94 FXR, FXRS, FXRC
23-8746* 26, 28, 45 23-8846*
46
1989-93 FXRS Convertible
23-8749* 26, 28, 45 23-8846*
46
1999
FXR4
Lower Lines Only
23-8958 1984-87 FXRT-FXRD
-4”
45
Lower Line Only
*Note: D.O.T. approved.
Brake Line
Fittings Shown
for Reference
Only
23-8833
23-8749
23-8846
23-8958
23-8836
