270
Steel Brake Rotor feature fine finish ground surface. Available with or without holes in steel
with zinc finish unless noted as stainless. Exactly interchangeable with stock discs. Order bolt
set separately.
Steel Brake Rotor
23-0300
Replica Brake Discs feature full stainless construction with
precision ground finish and slot style pattern.
VT No.
Year
Fits
Finish
23-0467 1992-99 Front
Stainless
23-0468 1992-99 Rear
Polish
23-0584 2000-14 Front
Polish
23-0775 2000-14 Front
Stainless
23-0585 2000-14 Rear
Polish
Note: 2000-up discs have 2.25” inner diameter center hole,
1979-99 discs have 2.062” inner diameter center hole.
Floating Brake Rotor
23-0583
Stainless Brake Rotor
23-0468
23-0775
11.5” Polished Stainless
Steel Floating Brake Rotor.
Order bolt set separately.
Rear
VT No.
Fits
23-0583 1979-99
23-0599 2000-up
Front
23-0596 1996-99
23-0595 2000-14
23-0595
Floating Center Detail
Drilled
Plain
OEM
Dia
Bolt Kit
Fits
Type
Front
23-0370 —
44210-79
10”
8792-5
1979-83 FLT
Steel
23-0300 —
44136-84
44136-92
11.5” 8793-5 Cast
8794-10 Wire
1984-99 FX FXST-FXSTS-FLST-FLT
Cast or Wire Wheel
Zinc
23-3774 —
44136-00
11.5” 8793-5 Cast
8794-10 Wire
2000-14 FXD, FLT, 2000-13 FLT
Cast or wire wheel right side brake disc
Stainless Steel
—
—
44260-00
11.5” 8793-5 Cast
8794-10 Wire
2000-14 FXSTS-FLSTS
Cast or wire wheel right side brake disc
Stainless Steel
Rear
23-0307 23-0308 41791-79
11.5” 8791-10T
1981-92 FXST-FXR Cast or Wire
Steel
23-0297 —
40909-81A 12”
8791-10
1981-84 FLH Cast or Wire .390 thick.
Steel
11.8" Front Brake Disc requires bolt on application, as the
original. OEM No: 42040-06. Diameter measures to be 11.8".
Must order mount bolts separately. Fits 2006-17 FXD, 2015-up
FXST, FLST, 2008-13 FLT.
Stainless Steel Polished
23-1000
23-0907
23-1000
23-0907
11.8” Stainless Steel Floating Rotor
VT No.
Finish
23-0230 S.S.
23-0231 S. S. Black
23-0232 S. S. Mirror Polish
23-0233 S. S. Black, Polish
23-0230
23-0231
23-0232
23-0233
