Forward Control Kit for 2006-17 FXD models with mid-controls.
Kit includes all components necessary to convert a mid-control
equipped Dyna® model to forward controls. Moves controls 11”
forward from mid-control foot position. Uses existing master
cylinder linkage and footpegs. Chrome finish. Available with
or with soft pegs. Both kits will require the removal of both the
inner and outer primaries for installation of kit. VT No. 22-0788
includes primary cover gaskets and seals for installation. VT No.
22-0794 will require separate purchase of primary cover gaskets
and seals for installation.
VT No. Type
22-0788 Without soft pegs
22-0794 With soft pegs
22-1679* Short Reach Adapter Kit, Black
22-0673 Short Reach Adapter Kit, Chrome
*Note: Move controls 1” closer to rider on FXD models when
22-0788 or 22-0794 are installed.
Note: Shifter Rod Position for Installation
Chrome Billet Forward Control Set fits 1991-05 FXD. Includes
rubber belted pegs as shown, and includes left and right sides.
Order shift rod separately. This kit will utilize stock master cylin-
der in the original position. Rod included fits directly to master
cylinder.
VT No.
Item
22-0770 Set
21-0222 Shifter Rod
22-0770 Right
Forward Control
for FXD-FXDWG
Dynaglide Chrome Forward Control Kit. The stock control kit
(22-0509) will move mid mount controls on 1991-05 Dynaglide
models to the forward position and can be used as stock replace-
ment on 1993-02 FXDWG. The 2” extended control kit (22-0510)
will move mid mount controls on Dynaglide models to the forward
position and can also be used on FXDWG for increased leg room.
Order foot rest and shifter pegs separately.
2006-up 1991-05
Item
—
22-0509
Control Kit, Stock
22-0561
—
Control Kit, Stock, Black
—
22-0510
Control Kit, 2” Extended
17-1009
—
Inner Lever
Chrome Brake Rods fit FXDWG models.
VT No. OEM
Year
23-9191 41955-93 1993-02
23-0850 41955-03 2003-17
23-9191
23-0850
22-1679
Right
Left
22-0788
22-0788
Reduced Reach Forward Control Kit moves VT No. 22-0708,
22-0794 and 22-0561 forward control kit closer to driver.
VT No. Finish
Fits
22-0673 Chrome
2003-17 FXDWG
22-0670 Black
2003-17 FXDWG
22-0673
Forward Controls on this page use existing master cylinder.
22-0509 Left
Billet Forward Control.
Black Polish Fits
22-0778 22-0779 2003-13 FXD
22-0779
22-0778
22-0770 Left
22-0561
22-0670
22-0788
