FXST Replica Forward Brake Control for use on all 1970-
99 Big Twin with Shovelhead or Evolution engines equipped
with hydraulic disc or drum brakes. Designed after the 1984-99
FXST which places the driver peg in back of the brake pedal,
so the brake is easier to operate from this comfortable position.
Redesigned to accept a Wagner or Kelsey-Hayes style master
cylinder or GMA masters, also available with chrome KH or
Wagner style masters. Hardware includes linkage pedal mount
plate, rubber covered footpeg. This kit is the exact compliment to
our shifter kits listed on opposite page and when used with one
of these kits, places the pegs in forward and raised position.
VT No. Item
22-1066 Dual-use kit without Master Cylinder
22-1001* Complete kit with Kelsey type Master Cylinder
22-1018* Complete kit with Wagner type Master Cylinder
23-1743 Brake Pedal for Above
13-0181 Brake Pedal Spring
Note: Kits VT No. 22-1001 and 22-1018 use Russell stainless
Lines VT No. 23-8809 front and 23-8802 from junction to rear
caliper. Use tee VT No. 23-0707.
Brake Control Kit
22-1001
Installed
22-1001
Installed
22-1082
Installed
Everything You Need To Convert
Hydraulic Brakes To Forward Control
22-1082
FXST Chrome Replacement Style Forward Control Kit
includes mounting brackets, levers and correct linkage for
1990-99 FXST models. Master cylinder not included.
VT No. 22-1085
for
FXST
28-0548
Shift
Brake
Right
Left
FXST Forward Control Kits
Brake Shift Type
Year
22-0522
22-0523
Chrome 2000-06
22-1064
22-1006
Chrome 1987-99
22-1082
22-1009
Chrome 1990-99
22-1085 Set
1990-99
22-0873
Set
Chrome 2000-17
22-0679 Chrome 200s7-17
22-0873
Installed
22-0873
Installed
Brake Pedal Pad with flame design. Fits
1984-up FXST. Bolt on.
VT No. Fits
23-0466 1984-up FXST Pedal Pad
23-1329 Grate Pedal
28-0548 OE Type
Chrome Brake Pedal Extender allows
the use of any style peg to be used as a
brake pedal pad. Fits 1984-up FXST.
VT No. 31-0053
Black Extended Forward Control
Mount Plates features an adapter
plate set to move stock forward
controls 3” more forward. Fits 2000-
17 FLST-FXST.
VT No. 22-0677
23-1329
23-0466
23-1329
23-1329
22-1085
