Parts for 1982-94 FXR
FXR Exhaust Bracket Mounting Block fits
1982-86 FXR models. Sold as each.
VT No. 28-0229
FXR Exhaust Set
30-9006 1984-94 Shovel (Paughco)
30-9007 1982-83 Evo (Paughco)
Drag Pipes
Drag Year
30-0885 1982-83
30-0886 1984-94
29-1145* 1984-94 FXR *Note: 2:1
30-0885 Installed
FXR Exhaust Pipe Brackets, zinc
plated.
VT No. OEM
Type
31-0189 65670-82 Front
31-0188 65671-82 Rear
31-1016 65670-82B 1986-94 Front
31-1028 65670-82B Chrome
31-1039 Weld On Raw
31-1735 65675-87 1982-94 FXR
31-0189
31-0188
FXR Triple Tree Sets.
VT No. Year
MM Finish
24-0806 1982-87 35 Lower Black
24-1322 1982-87 35 Polish/Black
24-1325 1988-94 39 Polish
24-0879 1988-94 39 Chrome
24-1322
24-1325
Top Engine Mounts for 1984-99 FXR.
VT No. Choke Mount
31-0119 Without
51-0429 Top Mount Tab Raw
31-0119
31-1039
31-1016
FXR Pipe Bracket Kit
VT No.
31-2147 Kit, Weld
31-0931 Kit, Bolt
FXR Exhaust Mount Bracket is bolt on type -
which attaches to pivot bolt cap screws.
VT No. 31-1552
31-1028
31-2147
31-0931
24-0879
FXR Petcock
fits 1982-94
FXR.
VT No. 35-1770
40 mm CV Carb Kit fits
1970-84 Big Twin. Includes
a replica 40mm CV carbure-
tor, manifold adapter, intake
clamps, a late flat intake
manifold seal and adapter
ring kit. VT No. 35-1751
35-0292
Shorty Carburetor Kit is for models
with o-ring type heads for intake mani-
fold. It has a relocated accelerator pump
nozzle for increased throttle response.
17•8” type intake manifold included. Fits
1978-84.
VT No. 35-0292
Triple Tree for 1988-94 FXR
VT No. Item
24-1331
Polished Top Tree
24-0865
Chrome Top Tree
28-1503 Top Bushing Set
37-0865
Screw Set
39mm Lower Triple Tree
VT No. Fits
Finish
24-0857 1987-94 FXLR Polished
24-1779 1987-94 Black
24-1331
24-0865
FXR 39mm Fork Assembly fits
1988-up models.
VT No.
Finish Fits
24-1757 Polish Dual
24-1772 Chrome Single
24-0857
28-1503
Top Triple Tree for FXR with 35mm tubes.
VT No. Year
Finish
24-0802 1982-87 Cast
24-0803 1982-87 Polished
24-0826 1982-87 Chrome
24-0802
24-0803
24-0826
24-0806
24-1772
30-9007 Installed
30-0885
31-1793
Clamp Set fits 1984-
94 FXR,
VT No. 31-0556
24-1779
Chrome Lower Triple Tree Cover. VT No. 42-0342
Chrome Lower Triple
Tree Cover fits 39mm forks
1987-94 FXR, 1991-2005
FXD. Designed for easy
installation. VT No. 42-0342
Front Fork Steering
Head Lock includes
lock, keys and cover.
Fits 1986-1992 FXR,
1988-99 FXST.
VT No. 24-1374
OKO Shorty Carb Enrichment Assembly
VT No. 35-1378
FXR Riser Kit
VT No. 25-2247
