241
BIG TWIN
1982-94 FXR-FXRS
1982-94 FXR
Chrome FXR Driver Footpeg Mount Brackets fit 1982-94 all FXR.
Use with male style pegs.
VT No. # OEM
Type
27-0640 B 50531-81
Right Mt
27-0639 C 50636-81A Right Ext
27-0638 A 50639-81
Left Ext
27-0641 Set
Chrome
27-0767 As Above Black
27-1821 1982-04
Peg Set, Zinc
27-0842 Left
Peg, Black
27-0831 Right
Peg, Black
27-0767
A
C
B
Footpeg Arm Mount Studs feature spline with 1/2”
threaded end, longer type is keyed (for FXR models),
overall length shown.
VT No. Length
27-0046* 27/8”
27-1648 23/8”
12-0201 Key for Above
*Note: Stud is keyed for positive mount.
27-0641
Driver Footpeg Set features zinc plated peg shafts with black rub-
bers and mount bolt set. Fits 1982-1994 FXR.
VT No. 27-1821
27-1821
27-0046
Rigid Mount Sissy Bar Side Strap and Backs. Order back and straps
separately,
Fitment
Side Straps 16” Back 11” Back Round
Width
1982-94 FXR 50-0806
50-0812
50-0816
50-0893 63/4”
50-0806
50-0812
Primary Cover for FXR
VT No. Sample Item/Finish
Fits
43-0233 43-0904 Inner Cast
1989-93
43-0204 43-0947 Outer Chrome 1982-84
43-0209 43-0951 Outer, Polish 1985-88
43-0333 43-0921 Outer, Polish 1985-88
43-0002
Outer, Black
1985-88
43-0233
43-0204
43-0209
43-0333
FXR Passenger Footpeg Kit
includes chrome brackets and bolts,
which moves passenger footpeg
higher and more forward. Stock or
custom 1/2” stud footpegs can be
used.
VT No. 27-1531
FXRP Solo Seat
VT No. Type
31-1110 Kit
47-0020 Seat
13-1983 Spring Set
31-3959 Black Bracket
31-2344 Cross Bracket
31-2936 Seat T Black Bracket
31-2937 Bracket
47-0020
31-2344
43-0002
Gas Tank for FXR
VT No. Type
Dash
38-0081 Bobbed
Without cutout
38-0116 1989-94
With
39-0845 1982-94
Bracket
38-0081
38-0116
Chrome Oil Tank fits 1982-94 FXR mod-
els. Includes mounting hardware and hose.
Replaces 62406-81.
VT No. 40-0094
Rear Fender Struts fits FXR-FXRS models.
Chrome Polished Year
50-1064 50-0286 1982-86 FXR
50-0287 Black
1982-86 FXR, 1983-91 FXRT
50-0305 —
1982-86 Left Only
50-1106 50-0285 1987-94 FXR
50-1064
50-1106
50-0286
50-0287
FXR Rear Seat Tab
VT No.
Item
31-4018
Tab
37-8858
Washers
Stock Type Rear Fender fits 1984-
94 FXR
VT No. 50-0768
13-1983
35-0710
Gas Tank Sender Units are digitally calibrated for accuracy.
Volt Tech
VT No. OEM#
Fits
35-1163
35-0710 75034-82
1982-94 FXR
35-1163
13-1983
