230
Outside Belt Guide Plate is for all Primo 8,
11, and 14 front pulleys except taper shaft.
VT No. 20-0230
Polished Alternator Cover for Big Twins.
Designed to protect your alternator, also helps
cooling by acting as a heat sink. Has a mount-
ing lug for belt shroud built in.
VT No. 20-0330
1990-up Primo Belt Drive Clutch Hub Nut and
Adjuster Kit will prevent oil leakage through the
mainshaft when using a belt drive system. Kit
includes clutch hub nut, seal and adjuster screw
with nut. Note: For Belt drive primary system only.
Splined (O-Ring Type).
VT No. 18-0201
Chrome Pike Motor Nut fits Big Twin 1955-up
sprocket shaft.
VT No. 37-0890
Acorn Motor Nut for Big Twins with splined
sprocket shaft.
VT No. 7816-1
Brute
20-0012
Note: There is no warranty on belts sold when as part of kit or
individual replacements.
8 mm Drive Kits
Kit
Repl. Belt Fits
20-0016
20-0554 1986-89 FXR-FLT
20-0017
20-0554 1990-93 FXR, FLT
20-0015
20-0554 1994-06 FXR-FLT
11 mm Drive Kits
20-0012
1994-99 FXST, 1994-99 FXD
Brute III from Primo Products includes dry clutch pack pulley
assembly which retains diaphragm spring function, while increasing
the clutch friction surface area 70% for smooth light fingered action.
Kit includes pulleys, 13/4” Kevlar reinforced rubber belt, complete
clutch pack/pressure plate assembly and necessary hardware, bolt
in kit. Available in 8 mm or 11 mm drive kits.
Replacement Clutch Set Includes 6 fiber plate and 7 steel
plates for all Brute belt drives.
VT
No.
Fits
Type
18-0555 Early Style with Flange
Brute III
18-0556 Late Style without Flange
Brute IV
18-0555
18-0556
Big Twin, 11/2” Wide
Ultima Carlisle BDL
# of Teeth Model
20-3000 20-4010 20-0441 136
1984-96 FLT-FLHT
20-3001 20-4011 20-0440 132
1986-92 FXST-FLST, 1994 FXST
20-3002 20-4012 20-0120 126
1980-86 FXSB-FXWG
20-3003 20-4013 20-0478 133
1991-99 FXD
20-3004 20-4014 20-0479 128
1993 FXST-FLST
20-3005 20-4017 20-0501 130
1995-99 FXST-FLST
—
20-4015 20-0500 127
Ratio Change
20-3006 20-4016 20-0455 135
Ratio Change
20-3007 20-4018 20-0579 139
1997-03 All FLT
Big Twin, 11•8” Wide
20-3008 —
20-0582 135
2000-05 FXST-FLST, 2000-06 FLST
20-3009 —
20-0586 133
2000-06 FXD
20-3010 —
20-0668 139
2004-06 FLT
Big Twin 20 mm Wide
—
—
20-0786 135
2006-up FXST
20-3011 —
20-0787 133
2007-up FXST
Big Twin 1” Wide
20-3012 —
20-4019 133
2007-11 FLST
20-3013 —
20-4020 137
2007-08 FLT
20-3014 —
20-4022 131
2007-17 FXD/FXDWG
Big Twin 24mm wide
— —
20-4023 133
2012-17 FXST, FLST
20-3015 —
20-4021 140
2009-up FLT
—
—
20-4024 134
2018-up All Softail models
Rear Belt
Narrow Belts.
VT No. Width Tooth Brand
20-0456 1.125” 125T BDL
20-0060 1.125” 128T BDL
Note: There is no warranty on belts when
sold as part of kit or individual replace-
ments.
20-0786
Final Drive Belts by Ultima, Carlisle or BDL.
20-0441
20-4023
