229
BIG TWIN
14mm x 33/8 Wide Drives
BDL Belt
Drives
BDL Front Belt Drive Parts
VT No. # Item
20-0925 A Inside Belt Guard
20-0926 B Outside Belt Guard
20-0927 C Motor Nut 55-up w/washer
A
B
C
BDL 3” Wide Offset Front Primary Drive Pulley. Use with
correct insert and nut for offset desired.
VT No. Item
20-0900 Pulley Only, 47T
20-0935 1/4” Insert and Nut
20-0937 3/4” Insert and Nut
20-0938 1” Insert and Nut
20-0940 11/2” Insert and Nut
20-0941 13/4” Insert and Nut
20-0900
20-0935
VT No. Fits
Belt
Front
Pulley
20-0605 1986-89 All FXST 20-0630 20-0902
20-0629 1994-06 All FXST 20-0630 20-0902
18-0554 Replacement Clutch Pack for Above Units
BDL 8mm x 42mm Electric Start Belt Drives. Includes a
polished pressure plate, Kevlar clutch, sealed inner primary
bearing and features a shorter length clutch hub that eliminates
unnecessary weight past the end of the mainshaft and can be
installed without any modifications to inner primary.
8mm x 42mm
BDL Belt Drive
Kits
BDL 3” Electric Start Belt Drives with billet motor plate.
Includes 8mm belt, polished motor plate, double row sealed
mainshaft support bearing, polished side guard, polished
dome pulley covers and Kevlar clutch.
VT No. Year
Belt
Front
Pulley
20-0601 1990-06 20-0603
20-0900
Sealed Inner Primary Bearing fits York
and BDL models.
VT No. 12-0993
Chrome Out Board Support
Kit fits 3” BDL and York Unit.
Includes hardware. For 3” drive
units.
VT No. 20-2052
20-0601
20-0603
20-0900
Note: There is no warranty on belts when sold as part of kit or
individual replacements.
A
BDL Belt Drive Parts
20-0928 A Round Dogs 5-Speed
20-0929 A Round Dogs 4-Speed
20-0930 B Splined Hub 1990-up 3” only
B
