Primary Drive Assembly
Primary Chain Drive Systems for Big Twins include 76 or
82 link Diamond primary chain, chain shoe adjuster assembly,
clutch drum basket with starter ring gear and steel and fiber
clutch plates with pressure plate assembly. Correct front com-
pensator sprocket assembly includes all parts necessary for
installation. Including sprocket nut. 5-Speed Big Twin Softail
models and all pre1985 FLH-FX 4-Speeds require 82 link
primary chains, 1980-up FLT-FXR 5-Speeds require 76 link
primary chains.
82 Links 76 Links
Year
18-0114* 1998-06
18-0103* 18-0113* 1994-97
18-0112* 1991-93
18-0111* 1985-90
*Note: Units include compensator front sprocket assembly.
18-0103
18-0114
18-0111
Primary Drive Assembly Kit includes clutch pack assembly,
chain, chrome inner and outer primary covers with all bush-
ings, seals, spacers, gaskets and mount screws including the
starter jack shaft assembly.
VT No. Years
43-1002 1994-97
43-1000 1998-06
Primary Drive Assembly
43-1002
43-1000
24T
Sprocket
25T
Sprocket
Nut Set
Motor
Spacer
Offset
—
—
—
19-0568
.25”
—
—
—
19-0561
.5”
—
—
—
19-0569
.75”
—
19-0161
—
19-0570
1.0”
19-0106
19-0162
—
19-0600
1.125”
—
—
19-0577
19-0601
1.5”
—
—
—
—
1.175”
—
—
—
19-0603
2”
Solid Mount
Sprocket without com-
pensator
For use with
compensator
components
Offset Components
