227
BIG TWIN
19-0299
VT No. Item
Note Fits
19-0299 Kit
1&3
2012-13 FXD, FXST, 2011-13 FLT
2009-13 FLHXXX
19-0014 Kit
1&3
As Above
19-0587
1,2,3 As Above
19-0159 Kit
2017-up FLT
12-1105 Hex Nut for Motor Sprocket
Note 1: Can also be used on 2006-11 FXD, 2007-11 FXST,
FLST and 2007-10 FLT but will require the separate purchase
of 32-0870 alternator rotor. 2006 FXD models will also require
the separate purchase of 32-0868 stator.
Note 2: Requires spring kit 13-0871 for installation.
Note 3: Stock replacement for 2014-17 FXD, FXST, FLST and
2014-16 FLT models.
19-0587
Compensator Bolt Torx Socket is for 2014-up Big
Twins. Used to remove or install compensator bolt.
VT No. 16-1669
Compensator Sprocket Kit. Engineered with heavier springs
for increased travel. Heavy duty kit should be used for higher
than stock horse power engines.
Compensator Sprocket Eliminator Kit fits 2007-16 FLT and
2007-17 FXST, FLST and FXD models as noted. Solid steel one
piece design sprocket kit is spring less and much quieter than
stock style compensator. Eliminates the need for a complete
compensator assembly. Kit includes washer, spacer, bolt and
sprocket.
VT No. Teeth Type
19-0295 24T 1984- FXR, 1984-93 FLT, 1991-93 FXD
19-0294 25T 1994-06 FX
19-0597 25T 1980-06 FX
19-0027 34T 2017-up M-8
19-0167 34T 2007-17
FLST, FXST, FXD, 2007-16 FLT
19-0175 34T Sprocket Only
19-0596 34T 2007-17 FX
19-0586* 30T Sprocket Only
19-0923** 30T Sprocket and Link Chain
19-0493
2007-16 FXST, 2011-13 FLH,
2006-2013 FXD
19-0028 32T 2006 FXD, 2007-16 FLT, 2007-17 FLST,
2007-2017 FXST
12-1102
Bolt Set
28-0483
Replacement Tensioner Shoe Only for 19-0028
*Note: Requires shorter primary chain. FLT applications require
VT No. 19-0933 primary chain and FXST, FLST, FXD applica-
tions require VT No. 19-0380 primary chain.
**Note: Includes VT No. 19-0933 84 link primary chain for FLT
applications only.
19-0167
19-0586
19-0923
Motor Sprocket
Compensator Sprocket Lock Nut Kit includes a lock plate
and lock tabs which secure the nut to the sprocket retainers
that the compensator nut and lock plate bolts do not come
loose. Similar to the transmission pulley mega nut. Use on all
Big Twins with VT No. 19-0299 or VT No. 19-0587 compensa-
tor sprocket kit only.
York Jims
19-0487 19-0475
19-0487
19-0475
19-0493
19-0028
19-0175
19-0027
13-0871
19-0295
19-0294
19-0159
19-0597
M-8
