201
BIG TWIN
Chrome 12 Point Head Bolt Set includes 8 washers
and 8 head bolts for 1986-91 FXST, FLST, FLT, FXR,
1986-92 XL and 1991 FXD.
VT No. 37-9019
11-0634
Head Bolt & Stud
for 1984-99 Evo
Sifton Racers Evo Stud Kit has 8 inserts, drill tap and 8 chro-
moly studs. Allows more torque to be applied, to cure oil leaks
and protects case threads during frequent disassembly. Detailed
instructions included.
VT No.
Item
11-0634
Complete Shop Kit
37-9259
8 Studs only
11-0636
8 Inserts only
Head Bolts and Hardware Kits for Evo 1340 models for one
head.
VT No. # OEM
Item
37-9521* 1986-91
Chrome Head Bolt Stud & Screw Kit
37-9322 As Above 1992-99, zinc
2011-8 E 16478-85A Head bolt, Chrome, 8 pack
F 16480-85A Screw set Late1985-91 Big Twin
2012-8 E 16478-85A Head Bolt Chrome, Colony, 8 pack
F 16480-92 Screw Set 1992-up Big Twin
37-8951 G 16837-85A Studs only, 1986-99 Big Twin 8 pack
9424-8 G As above Colony, 1986-99 Big Twin
37-9259 G As Above Sifton
37-8935 H 16573-83 Insert, 8 pack
12-1187 I 16715-83 Exhaust Stud, 5 pack
14-0516 J 26432-76 O Ring, 10 pack
37-9074 D 16482-83 Washer 1984-Early 85, Zinc, 4 pack
37-9075 D 16482-85 Washer Late1985-92, Zinc, 4 pack
*Note: For Both Cylinder Heads
Cylinder Oil Passage Drain Tubes for stock bore size cylin-
ders only. Each kit is supplied with tap, hex wrench, two drain
tubes and instructions. Fits Evo.
VT No. Item
16-0911 Kit
16-0912 Pair Replacement Tubes only
VT No.16-0911 Tube Installed
VT No. 16-0911
37-9521
37-8951
Components for One Head
37-8935
12-1187
Remove material
here to achieve
correct alignment
Underside of outer rocker box
cover
Umbrella valve
replace during
reassembly
Drain Hole Enlarge
with drill bit supplied
in kit
Rocker
Cover
Spacer
Install Slobber Stopper in this hole.
Tap threads in this hole using tap
supplied in kit
Sifton Evo Rocker Box Breather Upgrade Kit includes tap,
drill bit, breather tubes and instructions. Fits 1992-99 Big Twin.
VT No. Item
16-0914 Breather Upgrade Kit
16-1069 Breather Tube Insert Set
16-1069
16-0914
