166
Flywheel
VT No. OEM
Fits
Note
10-1091 23906-78G 1984-90 FXST, FLST 1,2
10-1042** 23906-93B 1993-99 FXST, FLST
FXD, 1993-84 FXR
1,2
Notes:
1. Features replaceable pinion and sprocket shafts and narrow sprocket
side flywheel
2. Require use of 1987-up type pinon shaft bearing and retaining ring.
Complete Stock
Stroke Flywheel
Assembly is shipped
assembled and trued
with shafts. VT No.
10-1091 requires the
use of 1987-up type
Pinion Shaft Bearing
assembly and VT No.
12-0967 late bearing
retainer.
10-1042
featuring hole plug.
.0625” hole, .252” x .160”.
.0935” hole, .252” x .160”.
Timken Bearing Sleeve will convert 2003-17 Twin
Cam models from a roller bearing to a Timken
tapered bearing. Bearing sold separately.
VT No. 10-0856
Important Note: Some items on this page may be emission-related parts subject to CA or NY or other emission control laws. Please see
note on for important information regarding emission control regulatory compliance and warranty information.
V-Twin Motor Shop Twin Cam Flywheel Remanufacturing Services
Flywheel that are out of round or scissored can be repaired. The new flywheels
on the 1999-up Big Twin are pressed together, but no match for our V-Twin Motor
Shop. We will press apart and disassemble this style wheel assembly, inspect
shafts, and crank pin components. V-Twin Motor Shop will rebuild your Twin Cam
flywheel assembly to OEM specification using new bearings, crank pin and solid
plugs, then balance and true. We can also weld the pin and plugs, if requested,
at the flywheel and crank pin interface, for rigid power. We stock the bearings,
cages and oversize crank pins to provide you with the components at hand when
your flywheel arrives. We will hone the rods to allow the oversize pin to be fitted
as required. Flywheel set will be trued and balanced. The final assembly and
press is complete in our dedicated TC-88 flywheel fixture assembly.
VT No. Service
60-0249 Twin Cam Remanufacturing Service
60-0248 TC Remanufacturing with New Connecting Rod Set
60-0247 Crank Pin/Plug Welding Service
60-0123 High Speed Balancing w/a flywheel remanufacturing service
S&S Twin Cam 3 Piece Flywheel Assemblies feature heat-treat-
ed 4140 material that is 114% stronger than stock. Larger 1.671”
crankpin for increased crank-pin clamping force. Integral main-
shafts eliminates two potential points of weakness. Reduced main-
shaft deflection at high rpm, less vibration, reduced piston and rod
side thrusting, prevents oil pump damage, fully compatible with
gear drive cams. 2007-up stock rod length is 7.659”. Stock pistons
in 2007 and later engines require rods with tapered wristpin ends.
Note: Flywheel assemblies supplied with sprocket shaft bearing
race installed are compatible with stock roller style sprocket shaft
bearings. Assemblies with no race require a Timken sprocket shaft
bearing.
V-Twin can provide quality professional machine shop and engine
building service through a Motorshop. We can handle any job from
fitting a set of pistons in your cylinder to complete rebuild of any
engine. Contact your V-Twin customer representative for details.
Flywheel Assembly Balanced for 1230 grams total piston
weight
Base and Head Gasket Sets
VT No. Brand Head Gasket Type Thickness Fits
15-1298 V-Twin Graphite
1996-up TC-88
15-0312 GB
Copper
1984-99 Evo 80"
15-0414 James Fire Ring
.045"
1984-98 FXST, FLT 1991-98 FXD
1984-94 FXR 1986-up XL 1200
15-0877 James Fire Ring
.062"
1984-98 FXST, FLT 1991-98 FXD
1984-94 FXR 1986-up XL 1200
15-1234 James Fire Ring
.045"
Special application for S&S 4" bore cylinders
15-1235 James Beaded
.045"
1999-17 FXST, FLST, FLT, FXD
15-1293 GB
Fire Ring
.045"
1999-17 FXST, FLST, FLT, FXD
15-0887 V-Twin Fire Ring
1966-84 FL 1971-84 FX 1979-83 FLT
1982-83 FXR
10-1871
4” stroke 1999-02 FXST, FLST, FLT, FXD 88” & 95”
VT No.
Engine Type
Sprocket Shaft
10-3500* Non-Balancer Type
Without Race
10-3501* Balancer Type
Without Race
4” Stroke 2003-06 FXST, FLST, FLT 99-05 FXD 88” & 95”
VT No.
Engine Type
Sprocket Shaft
10-3502* Balancer Type
With Race
10-3503* Non-Balancer type
With Race
4-3/8” Stroke 1999-2006 FXST, FLST, FLT, FXD
96”,103”,106”,110”, 117”
VT No.
Engine Type
Sprocket Shaft
10-3504* Non-Balancer Type
Without Race
10-3506* Balancer Type
Without Race
10-3515* Non-Balancer type
With Race
10-0845* Non-Balancer type
With Race
4-3/8” 2007-2016 FXST, FLST, FLT, FXD 96”, 103”, 106”,
110”, 117”
VT No.
Engine Type
Sprocket shaft race
10-3507* Non-balancer Type
Without Race
10-3508* Balancer Type
With Race
10-3510** Non-balancer Type
Without Race
10-3512 ** Balancer Type
Without Race
10-3513* non Balancer type
Without Race
10-3514* Balancer Type
Without Race
10-0846** non Balancer type
With Race
10-0847** Balancer Type
With Race
*Note: For use with the early style piston. Connecting rod is
straight at wrist pin end.
**Note: For use with 2007-up stock type piston. Connecting rod
is tapered at the wrist pin end.
